• Model NO.：GTBZ14J

 GTBZ14JItem ParameterTransport Condition Parameter Overall dimension (length × width × height)6.65×2.26×2.13 mWorking platform overall dimension 1.83×0.76×1.15 mMaximum  speed 6.12 km/hMax climbing capacity ≥30% (for two-wheel drive)   ≥45% (for four-wheel drive) Min outside turning radius ≤4.5mGround clearance (centre)0.41 mAxle distance 2.1 mTotal mass 6900 kgMain Operational Performance ParametersRated working height 15.9 mMax platform height 14.2 mMax working range 8.22mMax span head room7.14 mLuffing scope of No.1 Arm0°~60°Luffing scope of No.2 Arm-9°~75°Luffing angle of crank boom-60°~80°Platform swing angle 180°Rotary angle 355°discontinuous rotation Rotary table turning radius 1.145 mMax payload 230 kgMax tail wagging 0 mControl system12V DC proportional controlEmergency operation unit 12V DC battery pump Tyre315/55 D20 pouring off road tyre(standard configuration, optional solid tyre)Weighting detection Standard configuration Axle balance system Standard configuration Working Speed Parameters Platform lifting speed 0.1-0.3m/sTelescope speed of No.2 Arm0.1-0.3m/sRotation speed 0.5-1r/minMotor Parameters Manufacturer Perkins / DeutzType Perkins 404D-22/ Deutz D2011 L03iRated power 38KW/3000rpm
