XCMG Gtbz18A1 Cheap Hydraulic Telescopic Boom Lift Aerial Work
XCMG E-Commerce Inc.- Other Country：Jiangsu, China, Cn;Jia
- Type：Articulating Boom Lift
- Trademark：XCMG
Base Info
- Model NO.：GTBZ18A1
Description
Item
Unit
Parameter
a. Overall length
mm
9080
b. Overall width
mm
2490
c. Overall height
mm
2680
d. Wheelbase
mm
2500
Maximum working height
m
20.3
Maximum platform height
m
18.6
Maximum working range
m
11.9
Maximum load weight
kg
230
No.1 arm luffing range
°
0 ~ +70
No.2 arm luffing range
°
0 ~ +75
Crank arm luffing range
°
-65 ~ 70
The swing angle of the rotary table
°
360
Maximum tail wagging
mm
0
Platform size
mm
1830×760×1150
The swing angle of the platform
°
180
Machine weight
kg
10600
Maximum travelling speed
km/h
6.0
Minimum turning radius
m
6.0
Minimum ground clearance
mm
230
Maximum gradeability
%
45
Tyre size
355/55D625
Motor model
Perkins 404D-22
Deutz D2011L03i
Rated power of motor
kW/(r/min)
38KW/3000rpm,
36.3 KW/2800rpm
