XCMG Gtbz38s Chinese Hydraulic Telescopic Boom Lift Aerial Work Platform
XCMG E-Commerce Inc.- Other Country：Jiangsu, China, Cn;Jia
- Type：Telescoping Lift
- Trademark：XCMG
Base Info
- Model NO.：GTBZ38S
Description
Item
Unit
Parameter
Overall length
mm
14060
Overall width (axle retracting/axle extending)
mm
2490/3800
Overall height
mm
3000
Wheel base
mm
3800
Max. working height
m
39.9
Max. platform height
m
38.2
Max. working radius
m
23.3
Max. load capacity
kg
230 (no limit)/340 (with limit)
Boom elevation range
°
-7~+75
Turntable slewing angle
°
360°
Max. tail swing (axle retracting/axle extending)
mm
2085/1430
Platform dimension
mm
2400×900
Slewing angle of platform
°
180
Overall weight
kg
20600
Max. travel speed
km/h
5
Min. turning radius (axle retracting/axle extending)
m
8.2/10.8(turning for twice)
5.8/6.8(turning for four times)
Min. ground clearance
mm
260
Max. grade ability
%
40
Tire specification
-
445/50D710
Engine mode
-
Perkins 1104D-44T
Cummins B3.3-85HP
Engine rated power
kW/(r/min)
55.5/2400
63/2600
