• Model NO.：GTBZ30S

Project

Unit

Parameters

a Full length of machine

mm

13380

b Full width of machine (shaft retraction / shaft extension)

mm

2490/3800

c Full height of machine

mm

3070

d Wheelbase

mm

3800

Maximum operation height

m

32.2

Maximum platform height

 m

30.5

Maximum operation margin

m

23.1

Maximum bearing weight

kg

340 (unlimited) / 480 (limited)

Boom variable amplitude range

°

-11~+75

Rotary table rotation angle

°

360°

Maximum tail pendulum (shaft retraction / shaft extension)

mm

2085/1430

Platform size

mm

2400×900

Platform rotation angle

°

180

Total weight

kg

18300

Maximum driving speed

km/h

5

Minimum turning radius

(shaft retraction / shaft extension)

m

8.2 / 10.8 (two turns)

5.8 / 6.8 (four turns)

Minimum ground clearance

mm

260

Maximum climbing ability

%

45

Tire specification

-

385/65D22.5

Engine model

-

Perkins 1104D-44T

Engine rated power

kW/(r/min)

55.5/2400
