XCMG Gtbz22s Hydraulic Telescopic Boom Lift Aerial Work Platform
XCMG E-Commerce Inc.- Other Country：Jiangsu, China, Cn;Jia
- Type：Telescoping Lift
- Trademark：XCMG
Base Info
- Model NO.：GTBZ22S
Description
Project
Unit
Parameters
a Overall length of complete machine
mm
10150
b Overall width of complete machine
mm
2490
c Overall height of complete machine
mm
2800
d Wheelbase
mm
2500
Maximum working altitude
m
23.7
Maximum platform height
m
22
Maximum working range
m
18.3
Maximum bearing weight
kg
230 (unlimited) / 340 (limited)
Boom range
°
-5~+75
Rotation angle of rotary table
°
360
Maximum tail pendulum
mm
1550
Size of platform
mm
2400×900
Rotation angle of platform
°
180
Total weight
kg
12500
Maximum running speed
km/h
6
Minimum turning radius
m
6
Minimum ground clearance
mm
230
Maximum grade ability
%
45
Tire specification
-
355/55D625
Engine model
-
Perkins 404D-22T/Deutz D2011 L04i
Rated power of engine
kW/(r/min)
43/(2600)
41/(2300)
