Construction Hoist Crawler Crane, 100 Ton Quy100 Crane
Evangel Industrial (Shanghai) Co., Ltd.- After-sales Service：Available
- Warranty：1 Year
- Rated Loading Capacity：100t
- Rated Lifting Moment：5500kn.M
- Max. Travel Speed：1.1 Km,H
- Max. Single Unit Dimensions：9.6*3.3*3.3m
Base Info
- Model NO.：QUY100
- Gradeability：30%
- Transport Package：N,P
- Specification：CE, ISO9001
- Trademark：EVANGEL
- Origin：Jiangsu, China
- HS Code：8426200000
- Production Capacity：300 Sets,Month
Description
Max. lifting capacity
Boom
t
100
Jib
t
11
Max. load moment
kN.m
5500
Boom length
m
18~72
Boom elevating angle
°
0~80°
Fixed jib length
m
12~24
Fixed jib offset
10°,30°
Max. single line hoist speed (at 5th layer with no load)
m/min
120
Max. single line elevating speed (at 5th layer with no load)
m/min
45
Max. swing speed
r/min
1.4
Travel speed
km/h
1.1
Min. elevating time
s
240
Winch hoist speed(with full load)
m/min
4
Max. grade-ability
30%
Mean ground pressure
MPa
0.0927
Engine output
kW
200
Total mass (main hook block,18m boom)
t
114
Max. base machine weight for transport
(without counterweight, L/R crawler, lattice boom)
t
40.0
Max. base machine dimension for transport (L×W×H)
m
9.6×3.3×3.3
