• Model NO.：DY7892092
• Standard：National Standards
• Rated Load：2000n
• Hoisting Speed：4.8~25.5m,Min
• Transport Package：Wooden Case
• Specification：CCS. CE. BV. EC
• Trademark：Deyuan
• Origin：China
• Production Capacity：500set,Month

Basic Info.

Model NO. DY7892092 Standard National Standards Rated Load 2000n Hoisting Speed 4.8~25.5m/Min Transport Package Wooden Case Specification CCS. CE. BV. EC Trademark Deyuan Origin China Production Capacity 500set/Month

Product Description

Electric Driven Rope Ladder Winch


Electric Winch For Aluminum Accommodation Ladder :
Accommodation ladder winch is a kind of short time working equipment mainly used for handing accommodation ladders upon the berthing of the vessel as well as handling the pilot ladders when the vessels enter the harbor. It is installed on deck and has symmetrical left and right models. Mainly divided into pneumatic and electric two types. The winches are categorized in five specifications:6KN,8KN,10KN,12KN,16KN.
1. A winch specially designed to lower, support and retract the gangway.
2. Winch for hanging side ladder.
3. Specially designed for lowering, maintaining and twisting the gangway, a winch with a storage rope reel.

Electric Winch For Aluminum Accommodation Ladder Features:
1.Model of accommodation winch:6KN,8KN,10KN,12KN,16KN
2.Power:1.5kw~6.3kw
3.Hoisting speed:6m/min
4.Certificate:CCS,EC,BV,ABS,NV,RINA




Rated  load	2000N
Support  load	3000N
Hoisting  speed	4.8~25.5m/min
Capacity  of  wire	22m
Motor  type	YZ-112L-6-H
Power	2.5kw
Rotate  speed	1100r/min
Power  supply	440v, 60hz
Duty  factor	30min
Moving  mode	manual

If you are interested in our products or have any questions, please feel free to contact us for more details.
Deyuan Marine has been waiting for your contact.
