• Model NO.：HD HT
• Feature：Explosion-Proof, Insulating, Spillover Valve
• Certification：GS, CE, RoHS, ISO 9001
• Load Capacity：1000kg to 5000kg
• Lifting Height：1000mm to 4000mm
• Quantity of Hydraulic Cylinder：2
• Voltage：as Per Customers′ Local Standard
• Color：Yellow, Blue, Red or as Per Customer Requiement.
• Quality Warranty：12 Months
• Way of Installation：on Ground or in Pit
• Lowering Speed：Adjustable
• Scissor Structure Qty：1unit
• Dropping Time：Weight Drop,Adjustable Speed
• Pump Station Place：Built-in or External (Optional)
• Function：Lifting
• Transport Package：High Quality Paper Box
• Specification：CE, ISO, SGS
• Trademark：SAGA FIRST
• Origin：China
• HS Code：8428909090
• Production Capacity：10000

Advantages:
1.Standard ramp make it easier to load and unload.
2.High quality pump station make it lift and fall very stably.
3.Anti-pinch scissor design; main pin-roll place adopts self-lubricating design which prolong life span.
4.Equipped with aluminum alloy blend-stop under the platform
5.Pressure relief valve prevent overload operation; Flow control valve make descent speed adjustable.
6.Explosion-proof valve stops platform lowering quickly when pipe bursts.
7.Up to American standard ANSI/ASME and Europe standard EN1570

Safety Precautions:
1. Automatic aluminum safety sensor: stop dropping once touch any obstacle
2.Explosion-proof valves: protect hydraulic pipe, anti-hydraulic pipe rupture.
3.Spillover valve: It can prevent high pressure when the machine moves up. Adjust the pressure.
4.Emergency decline valve: it can go down when you meet an emergency or the power off.
5.Overload protection locking device: in case of dangerous overload.
6.Anti-dropping device: Prevent falling of platform.

Certification:




Frequently Asked Questions:

1.How can customer  buy parts once it break down?
The scissor lift table adopt most of the common parts of hardware.You can buy the parts in your local hardware market or forklift parts shop.

2.How can customer repair the scissor lift table.
One of the great advantage of the equipment is with very very low failure rate.Even it breaks down,we can guide to repair it by video and repair instruction.

3.How long is the quality guarantee?
One year quality guarantee.If it breask down within one year,we can send the parts free of charge to you.

 Our Service:
1.We can design the customerized scissor lift table as per your requirement.
2.The most suitable model will be recommended to you once we know about your requirement.
3.Shipment can be arranged from our port to your destination port.
4.Opetion video can be sent to you if needed.
5.Maintenance video will be given once the scissor lift table break down to help you repair.
6.Parts of scissor lift table can be sent to you by express within 7 days if needed.
