• Model NO.：QY30V532
• Production Capacity：100 Sets, Month

Item
Value
Remarks
Working performance specification
Max. rated total lifting capacitykg
32000
Max. load moment of basic boomkN.m
1132
Max. load moment with max. main boom lengthkN.m
588
Max. lifting height of basic boomm
11.1
Max. lifting height of main boomm
40.5
Deformation of boom is not taken into consideration.
Max. lifting height of fly jibm
48.5
Working speed
Max. speed of single rope on main winch m/min
120
The 4 th  layer of drum
Max. speed of single rope onauxiliary winch m/min
100
The 2 nd  layer of drum
Derricking time of booms
40
Telescopic time of booms
80
Slewing speedr/min
0~2.2
Traveling specification
Max. traveling speedkm/h
78
Max. gradeability%
37
Min. turning circle diameter m
22
Min. ground clearancemm
220
Limits for exhaust pollutants and smoke
Comply with related standards
GB3847-2005

GB17691-2005 (StageIII)
Oil consumption per hundred kilometersL
45
Mass specification
Deadweight of crane in traveling conditionkg
32000
Complete vehicle kerb mass kg
31870
Front axle loadkg
7000
Rear axle loadkg
25000
Dimension specification
Overall dimensions (L×W×H)mm
12900×2500×3465
Base on outriggersm
5.36
Distance between outriggersm
6.1
Main boom lengthm
10.6~40.0
Main boom angle°
-2~80
Fly jib lengthm
8
Offset angle of fly jib°
0 , 30
Chassis
Model
ZLJ5323
Feature No:ZLJ5323V3.2

ZLJ5323V3.3T
Class
II
Engine
Model
WP10.270
QSC 260
Rated powerkW/r/min
199/2200
194/2200
Max. output torqueN.m/r/min
1100/1300~1600
1180/1500
