Fixed Winch with Failsafe Brake and Rope Spooling Device

Pingyang Construction Hoisting Machinery Co.
  • Type：Electric Winch
  • Driven Type：AC
  • Speed：Slow
  • Carrying Capacity：Weight Level
  • Tonnage：30T
  • Reel Number：1

Base Info

  • Model NO.：JM
  • Running Mode：Stationary
  • Feature：Insulating
  • Certification：ISO 9001
  • Standard：National Standards
  • Line Pull Capacity：1ton to 50ton
  • Motor：ABB or Normal Brand
  • Voltage：3phase, 380V(or Made as Local Voltage)
  • Rope Capacity：100m to 1000m
  • Color：as Customer Like
  • Brake：Failsafe Brake
  • Transport Package：Wooden Case
  • Specification：1ton to 50ton
  • Trademark：CH
  • Origin：Wenzhou, China
  • HS Code：8425319000
  • Production Capacity：100 Unitss,Month

Description

ModelJM2JM3JM5JM8JM10Line pull capacity (kg)200030005000800010000average speed (m/min)121010109Wire rope(mm):12.515.521.52630Reduction boxTypeJZQ350JZQ350JZQ400JZQ500JZQ650Transmission ratio23.3431.523.3431.540.17Drum (mm)Diameter/mm273325406500550Length4805206459001000Capacity(m)150180250300450motorTypeYZ160M2-6YZ160M2-6YZ160L-6YZR225M-8YZR250M1-8Power(kW)7.57.5112230Rotate speed(r/min)948948953720720Hydraulic BrakeYWZ-200/25YWZ-200/25YWZ-300/45YWZ-300/45YWZ-300Equipment Dimension (mm)1060x1500x7501600x1100x8201400x1910x9502050x1640x10002470x2280x1180Weight(kg)630680140030004000Fixed Winch with Failsafe Brake and Rope Spooling DeviceFixed Winch with Failsafe Brake and Rope Spooling DeviceFixed Winch with Failsafe Brake and Rope Spooling DeviceFixed Winch with Failsafe Brake and Rope Spooling DeviceNFixed Winch with Failsafe Brake and Rope Spooling DeviceFixed Winch with Failsafe Brake and Rope Spooling DeviceN
