Lifting Machinery Sc100 Small Construction Elevator

FANGYUAN GROUP CO., LTD.
  • After-sales Service：Provided
  • Warranty：1year
  • Type：Electric Hoist
  • Maximum Lifting Height：300m
  • Certification：CE, ISO9001:2000
  • Condition：New

Base Info

  • Model NO.：SC100
  • Color：Orange
  • Transport Package：Bulk
  • Trademark：FYG
  • Origin：Shandong, China
  • HS Code：8428909090
  • Production Capacity：1000 pcs,year

Description

Technical parameters

 Unit

 SC100 Height m

 300

 Rated load kg1000  Maximum capacity  9  Boom lift wweight kg≤200  Lifting speed m/min0-45 0-60 Electormotor  Model  YZEJ132M(L)-4
