• Model NO.：EPFC-W
• Power Source：Hydraulic
• Shape：as Picture
• Certification：GS, CE, RoHS, ISO 9001
• Sling Color：Yellow
• Color：Yellow
• Capacity (Retracted)：1000kg 650kg
• Capacity (Extended)：250kg 150kg
• Max Lifting Height (Retracted/Extended)：2220,3310mm 2260,3350mm 2250,3340mm
• Max Length Crane Extended：813mm 1220mm
• Max Length Legs Extended：600mm
• Retracted Size (W*L*H)：762*2032*1600mm 889*2794*1727mm
• Net Weight：500kg 480kg 770kg
• Transport Package：Timber Box
• Specification：3.5CBM
• Trademark：PLK LIFT
• Origin：China
• HS Code：8428909090
• Production Capacity：50000 Set Per Year

Basic Info.

Model NO. EPFC-W Power Source Hydraulic Shape as Picture Certification GS, CE, RoHS, ISO 9001 Sling Color Yellow Color Yellow Capacity (Retracted) 1000kg 650kg Capacity (Extended) 250kg 150kg Max Lifting Height (Retracted/Extended) 2220/3310mm 2260/3350mm 2250/3340mm Max Length Crane Extended 813mm 1220mm Max Length Legs Extended 600mm Retracted Size (W*L*H) 762*2032*1600mm 889*2794*1727mm Net Weight 500kg 480kg 770kg Transport Package Timber Box Specification 3.5CBM Trademark PLK LIFT Origin China HS Code 8428909090 Production Capacity 50000 Set Per Year

Product Description

Battery powered prepelled crane for saleIntroduction& Advantages:

Fully powered shop cranes (power hoist & power in/out boom) for moving loads quickly, easily, and safely. 24V DC drive and lift motor handles heavy-duty jobs. Ergonomic handle features easy-to-operate throttle with infinite adjustment of forward and reverse speeds, lift/lower controls, proprietary safety-enhancing emergency reverse function, and horn. Includes an electromagnetic disc brake with automatic dead-man feature that activates when user releases the handle. Powered shop crane has two 12V, 80 - 95/Ah lead acid deep cycle batteries, integral battery charger, and battery level gauge. Poly-on-steel steer and load wheels. 3-4 hours operation at full charge - 8 hours when used intermittently. Includes rigid hook with safety latch.

Model	Capacity (Retracted) (kg)	Capacity (Extended) (kg)	Lift Range Retracted/Extended	Max height crane extanded	Max length legs extended	Retracted size (W*L*H)	Net weight kg
EPFC-25	1000	250	44-1/4''-97''	110	103-1/8''	30''*80''*63''	500
EPFC-25AA	1000	250	44-1/4''-97''	110	103-1/8''	30''*80''*63''	480
EPFC-CB-15	650	150	44-1/4''-97''	105	--	35''*110''*68''	770

Our service

1.We can design the customerized electric floor crane as per your requirement.

2.The most suitable model will be recommended to you once we know about your requirement.

3.Shipment can be arranged from our port to your destination port.

4.Opetion video can be sent to you if needed.

5.Maintenance video will be given once the electric mobile lift platform break down to help you repair.

6.Parts of floor crane can be sent to you by express within 7 days if needed.

FAQ

1.How can customer  buy parts once it break down?

The electric mobile lift platform adopt most of the common parts of hardware.You can buy the parts in your local hardware market.

2.How can customer repair the floor crane.

One of the great advantage of the equipment is with very very low failure rate.Even it breaks down,we can guide to repair it by video and repair instruction.

3.How long is the quality guarantee?

 One year quality guarantee.If it breaks down within one year,we can send the parts free of charge to you.
