• Model NO.：MOW0201 MOW0202 MOW0203
• Feature：cargo lifting
• Certification：GS, RoHS, ISO 9001
• Capacity：1000
• table size：1300X820
• raising height：1780mm
• base size：1240X640mm
• Transport Package：Plywood Case
• Specification：210kgs
• Trademark：HOTON
• Origin：Shandong, China
• HS Code：87091190
• Production Capacity：50 PCS,Month

Basic Info.

Model NO. MOW0201 MOW0202 MOW0203 Feature cargo lifting Certification GS, RoHS, ISO 9001 Capacity 1000 table size 1300X820 raising height 1780mm base size 1240X640mm Transport Package Plywood Case Specification 210kgs Trademark HOTON Origin Shandong, China HS Code 87091190 Production Capacity 50 PCS/Month

Product Description

SCISSOR LIFT TABLE INTRODUCE
It is used to convey the goods from one working level to another.
The control panels are available at the designated floors and one the lift platforms.
Heavy capacity,platform size and lifting height can be chosen according to your actual needs.
Installed in the pit,do not occupy space.
When lifting up or down, up,down and stop three buttons control the lift.
Great load capacity, 120% capacity load test. skidproof platform.
Sensitive overload protection devices locking device for failing protection.

MODEL	UNIT	MOW0201	MOW0202	MOW0203
capacity	kg	1000	2000	4000
Min.height	mm	305	360	400
Max .lifting height	mm	1780	1780	2050
Platform size L×W	mm	1300×820	1300×850	1700×1200
Base size L×W	mm	1240×640	1220×785	1600×900
Lifting time	s	35-45	35-45	55-65
motor		2.2KW	2.2KW	2.2KW
Net weight	kg	210	295	520
