• Model NO.：LT0201 LT0202 LT0209
• Feature：cargo lifting
• Certification：GS, RoHS, ISO 9001
• min.table height：265mm
• lifting table size：700X450
• dia.of wheel：100mm
• max table height：755mm
• Transport Package：Plywood Case
• Specification：40kgs
• Trademark：HOTON
• Origin：Shandong, China
• HS Code：87091190
• Production Capacity：50 PCS,Month

Basic Info.

Model NO. LT0201 LT0202 LT0209 Feature cargo lifting Certification GS, RoHS, ISO 9001 min.table height 265mm lifting table size 700X450 dia.of wheel 100mm max table height 755mm Transport Package Plywood Case Specification 40kgs Trademark HOTON Origin Shandong, China HS Code 87091190 Production Capacity 50 PCS/Month

Product Description

INTRODUCTION:
High quality hydraulic ensure reliable long life
With CE certification
With protection bracket and brakes on rear wheel
Rugged all-steel construction
Easy clean and operation.
Foot controls for lifting and lowering.
Includes non-slip rubber foot pedal cover
Foot pedal operates hydraulic scissor lift tabletop.

MODEL	UNIT	LT0201	LT0202	LT0203	LT0204	LT0205	LT0206	LT0207	LT0208	LT0209
capacity	kg	150	250	500	750	1000	100	350	500	800
Min.table height	mm	265	330	435	435	445	435	435	440	470
Max.table height	mm	755	910	1000	1000	950	1430	1585	1575	1410
Table size	mm	700x450	830x500	1010x520	1010x520	1010x520	830x500	1010x520	1010x520	1010x520
Overall size	mm	950x450	1010x450	1185x520	1260x520	1260x520	1010x500	1260x520	1260x520	1260x520
Handle height	mm	1000	1100	1130	1130	1130	1100	1130	1130	1130
Dia. Of wheel	mm	100	125	150	150	150	125	150	151	152
Net weight	kg	41	78	118	120	137	90	150	168	165





Contact Us:

Miss Wynn Sales Manager TENGZHOU HOTON MACHINERY CO.,LTD Tel:0086 632 5633796 MP:0086 16678336698 hotonmachinery.en.made-in-china.com

Company Profile:

Tengzhou Hoton Machinery Co.,LTD was established in 2006, and is the professional machine manufacturer in China. There are 480 workers, of whom 60 are engineers. It has an area of 46,000 square meter, general assets 30,000,000. It has a store of 350 equipments and the good ability of products design & manufacturing. It has export quality permit from 2007, and has export right given by the State Foreign Economic Trade Committee in 2008.

The leading products: "Hoton" series of CNC machines, Lathes, Milling machines, Drilling machines,Grinding machines, Saws, Sheet metal machines, Metal forming machines, and other machine accessories.Some products have national patent.It has fourteen series, over eighty models by itself. It has the ability of making 100,000 sets every year. All the products are designed perfectly and has high quality high performance and low price, and the excellent quality guarantee system. The products have past ISO9001 and CE certification since 2009. The products have been export to five continents, over forty countries and areas. It resulted to the attraction of client abroad and home, the quickly promotion of products sale.

Tengzhou Hoton Machinery Co.,Ltd. is willing to make common progress and developments with all the customers. Quality first,Constantly perfecting skills.
