• Model NO.：MOW0401 MOW0402
• Feature：cargo lifting
• Certification：GS, RoHS, ISO 9001
• Capacity：400
• table size：1700X1000
• raising height：3000mm
• base size：1600X1000mm
• Transport Package：Plywood Case
• Specification：800kgs
• Trademark：HOTON
• Origin：Shandong, China
• HS Code：87091190
• Production Capacity：50 PCS,Month

Basic Info.

Model NO. MOW0401 MOW0402 Feature cargo lifting Certification GS, RoHS, ISO 9001 Capacity 400 table size 1700X1000 raising height 3000mm base size 1600X1000mm Transport Package Plywood Case Specification 800kgs Trademark HOTON Origin Shandong, China HS Code 87091190 Production Capacity 50 PCS/Month

Product Description

FOUR SCISSOR LIFT TABLE HF SERIES
Heavy duty design.
Meet EN1570 norm and ANSI/ASME safety standard.
STANDARD SAFETY FEATURES
Upper platform lifted with aluminum safety bar preventing descent on contact with obstructions.
Internal power pack equipped with relief valve against overloading and compensated flow valve for controlled lowering speed.
Heavy duty cylinders with drainage system and check valve to stop the lift table lowering in case of hose burst.
Safety clearance between scissors to prevent trapping during operation.
OTHER STANDARD FEATURES
Self lubricating bushings on pivot points.
Removable lifting eye to handling and lift table installation.
Max. Height could be 4210mm.

MODEL	UNIT	MOW0401	MOW0402
capacity	(Kg)	400	800
min.height	(mm)	600	706
Lifting height	(mm)	3000	4210
Size of platform	(mm)	1000×1700	1000×1700
Base size	(mm)	1000×1600	1010×1606
Lifting time	(s)	30-40	70-80
Down time	(s)	30-40	75-85
motor	KW	2.2	2.2
Net weight	(Kg)	800	750





Contact Us:

Miss Wynn Sales Manager TENGZHOU HOTON MACHINERY CO.,LTD Tel:0086 632 5633796 MP:0086 16678336698 hotonmachinery.en.made-in-china.com

Company Profile:

Tengzhou Hoton Machinery Co.,LTD was established in 2006, and is the professional machine manufacturer in China. There are 480 workers, of whom 60 are engineers. It has an area of 46,000 square meter, general assets 30,000,000. It has a store of 350 equipments and the good ability of products design & manufacturing. It has export quality permit from 2007, and has export right given by the State Foreign Economic Trade Committee in 2008.

The leading products: "Hoton" series of CNC machines, Lathes, Milling machines, Drilling machines,Grinding machines, Saws, Sheet metal machines, Metal forming machines, and other machine accessories.Some products have national patent.It has fourteen series, over eighty models by itself. It has the ability of making 100,000 sets every year. All the products are designed perfectly and has high quality high performance and low price, and the excellent quality guarantee system. The products have past ISO9001 and CE certification since 2009. The products have been export to five continents, over forty countries and areas. It resulted to the attraction of client abroad and home, the quickly promotion of products sale.

Tengzhou Hoton Machinery Co.,Ltd. is willing to make common progress and developments with all the customers. Quality first,Constantly perfecting skills.
