• Model NO.：GTZZ24Z
• Driven Type：Hydraulic
• Running Mode：Moving
• Feature：Aerial Work Platform
• Certification：CE, ISO 9001
• Structure：Aerial Work Platform
• Installation：Aerial Work Platform
• Type of Work：Aerial Work Platform
• Working Height：24m
• Lift Capacity：250kgs
• Fuel Tank Capacity：100L
• Hydraulic Tank Capacity：250L
• Drive Speed：6.3km,H
• Gradeability：30%
• Transport Package：Bulk
• Specification：SGS CE
• Trademark：KUDAT
• Origin：China
• HS Code：8427109000
• Production Capacity：100units,Month

M ODEL                                                        GT ZZ 24Z               MEASUREMENTS                            Metric                 USWorking height maximum*25.7m84ft3inPlatform height maximum24m78ft8inHorizontal reach maximum**13.6m44ft7ftAPlatform length-8ft model0.76m2ft6inBPlatform width-8ft model1.83m6ftCHeight-stowed2.82m9ft3inDLength-stowed10.7m35ftEWidth2.48m8ftFWheelbase2.6m8ft6inGGround clearance-center0.33m1ftPRODUCTIVITY                                   ()Lift capacity (restricted)230kg507lbsPlatform rotation160°Jib rotation135°Turntable Swing360°continuousTurntable tailswing0Drive speed -stowed6.3km/h3.9mphTravel speed -raised or extended1.1km/h0.68mphGradeability -stowed30%
25%Turning radius - inside      3.0m9ft10inTurning radius -outside
Turning radius - axle extendeded      outside5.2m17ftControls12V DC Proportional
12V DC ProportionalSolid tires/Foam filled33×12-20POWER                                                                                                Power sourceCummins B3.3-C60(45kw)Auxiliary power unit12V  DC
12V  DCHydraulic tank capacity250LFuel tank capacity100LWEIGHT ***                                                                                       2 2WD10450kg23037lbsSTANDARDS COMPLIANCE                   EN280JG/T5101Q/ADZV001-2008
