• Model NO.：GTZZ16Z
• Driven Type：Hydraulic
• Running Mode：Moving
• Feature：Insulating
• Certification：GS, CE, ISO 9001
• Working Height：18m
• Platform Height：16m
• Safe Load：200kgs
• Size of Platform：1.2*0.8*1.1m
• Outreach：13.4m
• Rotation of Jib：180°
• Rotation of Work Cage：180°
• Rotation Range：360°
• Overall Length ：8.47m
• Total Weight ：7380kg
• Transport Package：Nude
• Specification：CE
• Trademark：KUDAT
• Origin：China
• HS Code：8428909090
• Production Capacity：100units,Month

Basic Info.

Model NO. GTZZ16Z Driven Type Hydraulic Running Mode Moving Feature Insulating Certification GS, CE, ISO 9001 Working Height 18m Platform Height 16m Safe Load 200kgs Size of Platform 1.2*0.8*1.1m Outreach 13.4m Rotation of Jib 180° Rotation of Work Cage 180° Rotation Range 360° Overall Length  8.47m Total Weight  7380kg Transport Package Nude Specification CE Trademark KUDAT Origin China HS Code 8428909090 Production Capacity 100units/Month

Product Description

Main Specification:

1.Technical data

Type	GTZZ16Z
working height  (m)	18.00
Platform height  (m)	16.00
Safe load     (kg)	230
Size of platform  (m)	1.83×0.76
Outreach (m)	14.30
Rotation of jib	180°
Rotation of work cage	180°
Turntable Rotation	360° non continuous
Overall length     (m)	8.47
Overall width      (m)	0.92
Overall height     (m)	2.00
Total weight       (kg)	7380
Speed      (km/h)	0-1.5
Climbing	20%
Power	15KW Diesel engine + 2.2KW electric motor

2. Specification
-Made of high strength steel, and the European production of hydraulic, control, parts;
-Pipeline all the built-in, to avoid the sun and rain or foreign objects tangled;
-Shape lightweight, low pressure rubber tracks on the ground, can travel, work on any ground;
-Outrigger separately controlled to bypass obstacles in a limited space work;
-Reliable torque control to ensure that the vehicle will not roll;
-Wired remote control walks, working bucket with 220V outlet;
-Small size, compact and flexible;
