Competitive Price 90 Tons Truck with Brick Crane Qy90k
Evangel Industrial (Shanghai) Co., Ltd.- Rated Load：90 Ton
- Transport Package：Nude Package
- Specification：90
- Trademark：evangel
- Origin：China Jiangsu
Base Info
- Model NO.：QY90K
- HS Code：84294019
- Production Capacity：100
Description
Dimension
Unit
Overall length
mm
14700
Overall width
mm
2800
Overall height
mm
3900
Weight
Total weight in travel
kg
53000
Front axle load (axle 1, 2, 3)
kg
9000/9000/13000
Rear axle load (axle 4, 5)
kg
13000/9000
Power
Engine model
TAD720VE
OM457LAIII/9
Engine rated power
kW/(r/min)
174/2300
315/1900
Engine rated torque
N.m/(r/min)
845/1400
2100/1100
Travel
Max. travel speed
km/h
80
Min. turning diameter
m
23
Min. ground clearance
mm
315
Approach angle
°
20
Departure angle
°
16
Max. grade ability
%
45
Fuel consumption for 100km
L
60
Main performance
Max. rated total lifting capacity
t
90
Min. rated working radius
m
3
Turning radius at turntable tail
m
4.51
Max. lifting torque
kN.m
3234
Base boom
m
12.3
Fully extended boom
m
55
Fully extended boom+ jib
m
71
Longitudinal outrigger span
m
7.5
Lateral outrigger span
m
7.1
Working speed
Boom luffing time
s
75
Boom full extension time
s
600
Max. swing speed
r/min
≥2
Max. speed of main winch (single rope) (no load)
m/min
≥120
Max. speed of aux. winch (single rope) (no load)
m/min
≥85
