XCMG Official Gtjz1012 12m High Quality Self Propelled Hydraulic Scissor Lift
XCMG E-Commerce Inc.- Lift Mechanism：Scissor Lift
- Certification：Ce and Kc Certification
- Applicable Industries：Construction Works
- Overall Dimensions：2485*1170*2472(mm)
- Table Size：2276*1120*1254(mm)
- Weight：3000kg
Base Info
- Model NO.：GTJZ1012
- Lift Drive / Actuation：Hydraulic
- Warranty：2 Years
- After-Sales Service Provided：Online Support
- Transport Package：Well
- Specification：standard
- Trademark：XCMG
- Origin：Cn; Jia
- Production Capacity：10000 Unit,Units Per Year
Description
ItemUnit Parameters Overall length mm 2485 Overall width mm 1170 Overall height mm 2472 Maximum platform height m 10 Size of platform mm 2276×1120×1254 Platform extension length mm 900 Minimum turning radius m 0 Wheel base mm 1871 Minimum ground clearance mm 101/20 (pot hole protector rising/falling) The total mass in driving state kg 3000 Rated load kg 320 Load of extension platform kg 115 Lifting speed of working platform s 56~66 Falling speed of working platform s 43~58 Driving speed (high) km/h 3.5 Driving speed (low) km/h 0.8 Maximum driving platform height m 10 Maximum gradeability 25% Battery V/(Ah) 4×6(240) Charger A 30 Tyre specification Traceless solid core 38.1cm×12.7cm Incline alarming angle 1.5° (both sides) 3° (front and back)
