- Model NO.：QUY130
- Origin：China
- HS Code：8501109990
- Production Capacity：100set,Months
| Ser. No. | Item | Unit | Value | Remark |
| 1 | Maximum lifting weight ×radius | t×m | 130×4.5 | |
| 2 | Maximum lifting moment | T·m | 661.5 | 94.5 (lifting weight) × 7 (range) |
| 3 | Basic boom dead weight | t | 113.8 | |
| 4 | Length of main boom | m | 19~73 | |
| 5 | Length of fixed jib | m | 13~31 | |
| 6 | Maximum lifting weight of fixed jib | t | 13 | |
| 7 | Fixed jib installation angle | ° | 10,30 | |
| 8 | Maximum length of main boom + fixed jib | m | 55+31,58+25,61+19 | |
| 9 | Speed of rope on the drum of main winch | m/min | 105 | Drum outermost layer |
| 10 | Speed of rope on the drum of auxiliary winch | m/min | 93 | Drum outermost layer |
| 11 | Speed of rope on the drum of derricking winch | m/min | 52 | Drum outermost layer |
| 12 | Swing speed | r/min | 0~2.2 | |
| 13 | Travelling speed | km/h | 0~1.3 | |
| 14 | Gradeability | % | 30% | |
| 15 | Pressure to the ground | MPa | 0.1 | |
| 16 | Outline dimension length ×width ×height | m | 9.55×6.5×3.2 | Mast-free main boom |
| 17 | Engine rated power / speed | Kw/rpm | 209/2000 | |
| 18 | Engine maximum output torque / speed | N·m/rpm | 1424/1500 | |
| 19 | Engine emission standard | | U. S. EPA Tier III | |
| 20 | Crawler gauge ×crawler length × crawler width
| mm | 5600×6850×900 |
