• Model NO.：JCPT2223DC
• Driven Type：AC
• Running Mode：Moving
• Feature：Explosion-Proof
• Certification：CE, ISO 9001
• Platform Extension Size：2.70m
• Ground Clearance：0.40m
• Wheel Base：3.30m
• Maximum Occupants：4
• Gradeability：30%
• Battery：48V,630ah
• Hydraulic Tank：150L
• Weight：13400kg
• Transport Package：Nude Package
• Specification：4.95m*2.46m*3.86m
• Trademark：DINGLI
• Origin：Zhejiang, China
• HS Code：8427109000
• Production Capacity：1000units,Year

ModelJCPT2223DCMax. Working Height22.00mMax. Platform Height20.00mOverall Length4.95mOverall Width2.46mOverall Height(Rails up)3.86mOverall Height(Rails down)3.00mPlatform Size(Length×Width)4.59×2.25mPlatform Extension Size2.70mGround Clearance0.40mWheel Base3.30mModelJCPT2223DCS.W.L750kgS.W.L On Extension750kgMaximum Occupants4Turning Radius(Inside/Outside)1.25m/3.40mTravel Speed(Stowed)5.00km/hTravel Speed(Raised)0.40km/hUp/Down Speed90/100secGradeability30%Maximum Working Slope2°/3°Tyre36×14-20ModelJCPT2223DCBattery48V/630AhCharger48V/60ADriving Motor4×AC 32V/3.3kWLifting Motor2×AC 48V/8.0kWHydraulic Tank150L
