1ton~32ton Monorail Wireropr/Chain Rope Electric Hoist
Henan Kuangshan Crane Co., Ltd.- Application:Double Beam Crane, Gantry Crane, Bridge Crane, Tower Crane, Single Grinder Crane, Lifting Platform, Small Crane
- Type:Electric Hoist
- Sling Type:Wire Rope
- Lift Speed:2~8m,min
- Maximum Lifting Height:>3m
- Chain Falls:1~2
Base Info
- Model NO.:CD,MD
- Certification:CE, ISO9001:2000, SGS
- Condition:New
- Color:Blue
- Weight Overload Protection Device:Included
- B/T 28001-2001, Ohsas180011999:Pass
- Main Electrical Parts:Siemens or Chint Brand
- Motor:Nanjing or Nanjing Special Motor
- GB/T 24001-2004 Idt ISO140012004:Pass
- GB/T 19001-2000 Idt ISO 9001: 2000:Pass
- Control Method:Pendent Line with Push Button or Remote Control
- Capacity:2 Ton, 3ton, 5ton, 10 to, 15 Ton, 20 Ton
- Lifting Height:8m~100m
- Transport Package:High Quality Plywood Crate.
- Specification:Chinese Standard
- Trademark:Kuangyuan
- Origin:Xinxiang(Crane Hometown), Henan Province, China
- HS Code:84251100
- Production Capacity:20000sets,Year
Description
MD1Capacity (TON) 0.25 0.5 1 2 3 5 10 Lifting Height(M) 3-9 6-12 6-30 6-30 6-30 6-30 9-30 Lifting Speed(m/min) 8/0.8 8/0.8 8/0.8 8/0.8 8/0.8 8/0.8 7/0.7 Running Speed(m/min) 20(30) Wire rope Type 6x19-3.6 6x37-4.8-180 6x37-7.4-180 6x37-11-155 6x37-13-170 6x37-15-200 6x37-15-200 Lifting Motor Model ZD1 12-4 ZD1 12-4 ZDS1 0.2/1.5 ZD1 22-4 ZDS1 0.2/1.5 ZD1 31-4 ZDS1 0.4/3 ZD1 32-4 ZDS1 0.4/4.5 ZD1 41-4 ZDS1 0.8/7.5 ZD1 51-4 ZDS1 1.5/13 Capacity(Kw) 0.4 O.8 0.2/0.8 1.5 0.2/0.8 3 0.4/3 4.5 0.4/4.5 7.5 0.8/7.5 13 1.5/13 R.P.M(r/min) 1380 1380 1380 1380 1380 1400 1400 Running Model Dw5024 ZDY1 11-4 ZDY1 11-4 ZDY1 12-4 ZDY1 12-4 ZDY1 21-4 ZDY1 21-4 Capacity(Kw) 0.06 0.2 0.2 0.4 0.4 0.8 0.8X2 R.P.M(r/min) 1400 1380 1380 1380 1380 1380 1380 Motor 3P 380V 50Hz
