XCMG Gtbz32s Cheap Hydraulic Telescopic Aerial Lifting Work Platform Price
XCMG E-Commerce Inc.- Type：Telescoping Lift
- Transport Package：Well
- Specification：standard
- Trademark：XCMG
- Origin：Jiangsu, China, Cn; Jia
Base Info
- Model NO.：GTBZ32S
Description
Project
Unit
Parameters
a Full length of machine
mm
14300
b Full width of machine (shaft retraction / shaft extension)
mm
2490/3800
c Full height of machine
mm
3070
d Wheelbase
mm
3800
Maximum operation height
m
33.9
Maximum platform height
m
32.2
Maximum operation margin
m
24.6
Maximum bearing weight
kg
230 (unlimited) / 340 (limited)
Boom variable amplitude range
°
-6~+75
Rotary table rotation angle
°
360°
Maximum tail pendulum (shaft retraction / shaft extension)
mm
2085/1430
Platform size
mm
2400×900
Platform rotation angle
°
180
Total weight
kg
18400
Maximum driving speed
km/h
5
Minimum turning radius
(shaft retraction / shaft extension)
m
8.2 / 10.8 (two turns)
5.8 / 6.8 (four turns)
Minimum ground clearance
mm
260
Maximum climbing ability
%
45
Tire specification
-
385/65D22.5
Engine model
-
Perkins 1104D-44T
Engine rated power
kW/(r/min)
55.5/2400
