• Model NO.：CTY
• Specification：CE
• Trademark：NIU LI
• Origin：China
• HS Code：8427900000
• Production Capacity：Depends

Basic Info.

Model NO. CTY Specification CE Trademark NIU LI Origin China HS Code 8427900000 Production Capacity Depends

Product Description

Equipped with a constant velocity controlling value, Variation of loads do not effect forks lowering speed.
Top quality hydraulic pump and cylinder.
Compact design and strong steel construction

1. Capacity: 1000kg, 1500kg, 2000kg, 3000kg.
2. Max Lifting Height: 1600mm, 2500mm.
3. Height Of Forks: 80-100mm.
4. Fork Of Length: 900mm.
5. Adjustable Width Of The Forks: 320-750mm.
6. Self Weight: 155kg/190kg/250kg/360kg.

Model	CTY-A1.0	CTY-A2.0	CTY-A3.0
Capacity(kg)	1000	2000	3000
Max.lifting height(mm)	1600	1600	1600
Lowered height of forks(mm)	85	85	100
Fork length (mm)	900	900	1000
Adjustable Width of fork(mm)	230-580	270-680	320-770
Lifting speed(mm/stroke)	20	14	10
lowering speed(mm/stroke)	Controllable	Controllable	Controllable
Outer width of front legs (mm)	750	750	750
Operation power of crank(kg)	24	32	40
Min.refuel volume of fuel tank(L)	1.6	2.0	3.0
Front wheel size(mm)	φ85x50	φ85x50	φ100x50
Rear wheel size(mm)	φ180x50	φ180x50	φ180x50
Overall size(mm)	2040x750x1420	2050x750x1480	2050x800x1650
Self Weight(kg)	115	180	280
