2 Ton 380V Electric Chain Hoist for Lifting with Trolley
Shanghai Yiying Crane Machinery Co., Ltd.- Type：Electric Hoist
- Sling Type：Chain
Base Info
- Model NO.：HSY
- Lift Speed：6.6 M,Min
- Maximum Lifting Height：3m
- Chain Falls：2
- Certification：CE, ISO9001:2000
- Condition：New
- Color：Yellow
- Hoist Capacity：2 Ton
- Lifting Height：3 Meters or to Order
- Hoist Speed：6.6 M,Min
- Hoist Power Supply：3 Phase 380V or Customized
- Motor Power：1.5 Kw
- Limit Switch：Available
- Load Chain Daimeter：7.1 mm
- No.of Load Chain：2
- Chain Protection Bag：Yes
- Hoist Trolley：Avaliable
- Transport Package：Wooden Case with Pallet
- Specification：ISO,CE
- Trademark：HUGO
- Origin：Hebei, China
- HS Code：8425110000
- Production Capacity：5000 PCS,Yesr
- Package size per unit product：61.00cm * 49.00cm * 72.00cm
- Gross weight per unit product：97.000kg
Description
Drive motorPower
KW Rotational
Speed
R/MIN Phase Voltage
V Frequency
HZ/S Power
KW Rotational
Speed
R/MIN Running
speed
M/MIN Phase Voltage
V Frequency
HZ/S 01-01s 1 3/9 6.8 1.5 1440 3 380 50 0.4 1440 11/21 3 380 50 02-02s 2 3/9 3.4 1.5 1440 3 380 50 0.4 1440 11/21 3 380 50 2.5-01s 2.5 3/9 5.0 3.0 1440 3 380 50 0.75 1440 11/21 3 380 50 03-02s 3 3/9 3.0 3.0 1440 3 380 50 0.75 1440 11/21 3 380 50 05-02s 5 3/9 2.8 3.0 1440 3 380 50 0.75 1440 11/21 3 380 50
High quality 2 Ton 380V Electric Chain Hoist with trolley 1) Compact and high efficient motor, low power consumption 2) Hoist body pressing steel structure, high strength body, light and compact 3) Most tensile safety hooks: Both the top and bottom hooks are made of high tensile alloy steel with special treatment; It guarantees the hook will not break and deform gradually under a sudden extra-load 4) Compact and beauty chain container: High strength plastic container has outstanding durability 5) Limit switch devices fitted at both top and bottom ends: Switch off power automatically to prevent load chain from running out 6) widely used in mining and manufacturing enterprises,stores and warehouses ,medicine and healthy services,and catering trade,electric chain hoist can be fixed on a steel beam, curved track and fixed point for carrying anything heavy,and also on cantilever crane guide for carrying workpiece and machine tools. With the advantages of re lianle property,easy for operation,small size,light weight and good character isrics of common use, the block is good for the improvement of labor conditions and producivity.
Electric Chain Hoist with Trolley Making process
KW
Speed
R/MIN
V
HZ/S
KW
Speed
R/MIN
speed
M/MIN
V
HZ/S
Electric Chain Hoist with Trolley Making process
