Dy High Quality 15ton 20ton 25ton 380V 50Hz 3pH Electric Chain Hoist
Anhui Dingya Crane Co., Ltd.- Warranty：1 Year
- Application：Double Beam Crane, Gantry Crane, Bridge Crane, Single Grinder Crane, Small Crane
Base Info
- Model NO.：CD
- Type：Chain Hoist
- Sling Type：Chain
- Lift Speed：2~8m,min
- Maximum Lifting Height：>20m
- Chain Falls：2
- Certification：CE
- Condition：New
- Color：Yellow or Customized
- Product Name：Electric Chain Hoist
- Feature：Easy Operation
- Power Supply：Electric
- Environment Temperature：-20~40 ºC
- Material：Steel Structure
- Working Duty：A3
- OEM：Available
- Control Method：Pendant +Remote(Customized)
- Lifting Height：Standard 3m or Customized
- Transport Package：Wooden Case,Bubble Wrap or Others
- Specification：2t
- Trademark：Dingya
- Origin：China
- HS Code：8425110000
- Production Capacity：2000 Pieces,Year
- Package size per unit product：100.00cm * 200.00cm * 300.00cm
- Gross weight per unit product：1000.000kg
Description
TypeCapacity
(Ton) Lifting Height
(m) Lifting Speed
(m/min) Operating Motor Power
(KW) Rotation Speed
(m/min) Phases Voltage
(V) Frequency
(HZ) Power
(KW) Rotation Speed
(m/min) Operating Speed(m/min) Phases Voltage
(V) Frequency
(HZ) DYHB0.5-01 0.5 3/9 7.2 1.1 1440 3 380 50 0.4 1440 11/21 3 380 50 DYHB01-01 1 3/9 6.8 1.5 1440 3 380 50 0.4 1440 11/21 3 380 50 DYHB01-02 1 3/9 3.6 1.1 1440 3 380 50 0.4 1440 11/21 3 380 50 DYHB1.5-01 1.5 3/9 8.8 3.0 1440 3 380 50 0.4 1440 11/21 3 380 50 DYHB02-01 2 3/9 6.6 3.0 1440 3 380 50 0.4 1440 11/21 3 380 50 DYHB02-02 2 3/9 3.4 1.5 1440 3 380 50 0.4 1440 11/21 3 380 50 DYHB2.5-01 2.5 3/9 5.6 3.0 1440 3 380 50 0.75 1440 11/21 3 380 50 DYHB03-01 3 3/9 5.6 3.0 1440 3 380 50 0.75 1440 11/21 3 380 50 DYHB03-02 3 3/9 4.4 3.0 1440 3 380 50 0.75 1440 11/21 3 380 50 DYHB03-03 3 3/9 2.2 1.5 1440 3 380 50 0.75 1440 11/21 3 380 50 DYHB05-02 5 3/9 1.8 3.0 1440 3 380 50 0.75 1440 11/21 3 380 50
FAQ
Q,What products does your company mainly deal with?
A,Electric chain hoist,electric wire rope hoist,bridge crane,gantry crane ,wireless remote control,hook etc.
Q,What information do I need to provide when making an inquiry?
A,Product information: Quantity, Specification (capacity, lifting height, voltage, size, material, color and packing
requirements) .
Q,What is your payment method?
A: 30% deposit, with the balance before delivery, we accept T/T, Western Union and L/C at sight.
