• Model NO.：GTBZ18J
• Running Mode：Stationary
• Feature：Explosion-Proof, Insulating
• Certification：GS, CE, RoHS, ISO 9001
• Platform Height Max.：18m
• Working Height Max.：20.4m
• Horizontal Extended：12.1m
• Lift Capacity：250kg
• Gradeability：40%
• Transport Package：Nude
• Specification：1.45*0.85*1.24m
• Trademark：SINOBOOM
• Origin：China
• HS Code：8454651321
• Production Capacity：100units,Month

Models

GTJZ0408S

GTJZ0608S

GTJZ0608

GTJZ0808

GTJZ1012

GTJZ1212

Platform height max.

4.6m

5.8m

6.3m

8.1m

10m

11.9m

Working height max.

6.6m

7.8m

8.3m

10.1m

12m

13.9m

Horizontal extended

0.9m

0.9m

0.9m

0.9m

0.9m

0.9m

Lift Capacity

280kg

230kg

380kg

250kg

320kg

320kg

Gradeability

30%

30%

30%

25%

25%

25%

Length-stowed

1.775m

1.775m

2.39m

2.39m

2.39m

2.39m

Width-stowed

0.76m

0.76m

0.81m

0.81m

1.15m

1.15m

Height-stowed

2.08m

2.06m

2.22m

2.35m

2.48m

2.6m

Ground clearance

0.07m

0.07m

0.1m

0.1m

0.1m

0.1m

Wheelbase

1.315m

1.315m

1.85m

1.85m

1.85m

1.85m

Platform size(L*W*H)

1.64*0.76*

1.1m

1.64*0.76*

1.1m

2.25*0.81*

1.1m

2.25*0.81*

1.1m

2.25*1.15*

1.1m

2.25*1.15*

1.1m



*ARTICULATING BOOM LIFT*

Models

GTZZ14EJ

GTZZ15

GTZZ15J

GTZZ18J

GTZZ25J

Platform height max.

13.7m

14.8m

15m

18.4m

24.6m

Working height max.

15.7m

16.8m

17m

20.4m

26.6m

Horizontal extended

7.4m

7.62m

8.5m

12.1m

16.1m

Up and over clearance

max.

7.4m

7.5m

7.5m

7.9m

9.4m

Lift Capacity

227kg

250kg

250kg

250kg

230kg

Gradeability

30%

30%(2WD)40%(4WD)

30%(2WD)40%(4WD)40%45%

Length-stowed

6.54m

5.7m

7.68m

8.6m

11.36m

Width-stowed

1.75m

2.26m

2.26m

2.28m

2.48m

Height-stowed

1.99m

2.16m

2.16m

2.54m

3.16m

Ground clearance

0.2m

0.32m

0.32m

0.23m

0.39m

Wheelbase

2m

2.03m

2.03m

2.44m

3.05m

Platform size(L*W*H)

1.52*0.77*1.14m

1.45*0.85*1.24m

1.45*0.85*1.24m

1.45*0.85*1.24m

1.45*0.85*1.24m



*TELESCOPIC BOOM LIFT*



Models

GTBZ20

GTBZ22J

GTBZ26

GTBZ28J

GTBZ30

GTBZ32J

GTBZ36

GTBZ38J

GTBZ42J

Platform height max.

20.6m

22.2m

25.8m

27.7m

30.4m

32m

36.5m38.1m41.6m

Working height max.

22.6m

24.2m

27.8m

29.7m

32.4m

34m

38.5m40.1m43.6m

Horizontal extended

17.5m

18m

22m

21m

22.3m

24.4m

21m22.5m24.38m

LiftCapacity

340kg

250kg

480kg

250kg

480kg

250kg

480kg250kg480kg

Gradeability

30%(2WD)

45%(4WD)

30%(2WD)

45%(4WD)

30%(2WD)

45%(4WD)

30%(2WD)

45%(4WD)

42%42%40%40%40%

Length-stowed

9.57m

11.2m

11.54m

13.22m

13m

14.02m

12.5m14.02m13.1m

Width-stowed

2.49m

2.49m

2.49m

2.49m

2.49m

2.49m

2.49m2.49m2.49m

Height-stowed

2.84m

2.84m

2.88m

2.88m

3.08m

3.08m

3.08m3.08m3.05m

Ground clearance

0.45m

0.45m

0.41m

0.41m

0.43m

0.43m

0.43m0.43m0.65m

Wheelbase

2.49m

2.49m

3m

3m

3.66m

3.66m

3.66m3.66m3.81m

Platform size(L*W*H)

1.45*0.85*

1.24m

1.45*0.85*

1.24m

1.45*0.85*

1.24m

1.45*0.85*

1.24m

1.45*0.85*

1.24m

1.45*0.85*

1.24m

1.45*0.85*

1.24m

1.45*0.85*

1.24m

2.44*0.91*

1.14m
