• Model NO.：SSL2-5
• Feature：Explosion-Proof, Insulating
• Certification：CE, ISO 9001
• Lift Speed：3-6m,Min
• Voltage：220V,380V, AC Power, 1 or 3 Phase, Can Also Be Mad
• Guardrail(Optional)：1000mm
• Platform：Antiskid
• Color：Yellow, Blue, Green, Black as Your Requirement
• Installation：in Pit or Directly on Ground
• Max Load Capacity：1.2 Times Rated Load
• Surface：Rust-Proof
• Painting：Epoxy Paint
• Lifting Hook：4 Lifting Hooks for Easy Moving and Install
• Transport Package：Plywood Case or Nude Packing Based on Actual Need
• Specification：CE
• Trademark：Morn
• Origin：Shandong, China
• HS Code：84289090
• Production Capacity：50PCS Per Month

ModelLoad capacityLifting heightWeightPlatform sizeMin heightMax heightSSL1-31000kg3000mm16001600x1200mm782mm3782mmSSL1-4.81000kg4800mm20002000x1500mm782mm5582mmSSL1-6.31000kg6300mm32803000x2385mm836mm7136mmSSL1-7.91000kg7900mm31002000x1800mm984mm8884mmSSL2-4.52000kg4500mm33002500x2200mm850mm5350mmSSL2-6.32000kg6300mm34002800x2000mm918mm7218mmSSL2-52000kg5000mm30004500x2160mm850mm5350mmSSL3-6.43000kg6400mm85007000x4000mm910mm7310mm

Please do not be confined to above listed models, as the car lift is customizable in loading capacity, platform size, and lifting height for your individual requirements. So please inform your specific need.

 Advantages

1. Mature hydraulic lifting system, remote control and multi-control points at the different floors could be realized;
2. Lift Up, Stop and Lower be easily realized at each control point to make sure the lift platform stop at the accurate level point.
3. Smooth working condition, high load capacity, safety controls and reliable performance.
4. Power supply is from local power source, customize according to local voltage.



Packing&Shipping

Packaging details for goods elevator:

1. Film package to prevent humidity and rust.
2. Iron frame to keep warehouse goods lift stable in container.
3. Plywood to prevent warehouse goods lift from colliding. Convenient for forklift delivery.




Delivery time: within 30 working days after we receive the payment.

Different size car lift for your reference


Customers visit




Service:

(1) All machines sold must be tested before shipment, 100% quality.

(2) 1 year warranty without man-made fault, and have CE certification.

(3) 24hours technical support by email, telephone or video online.

(4) User-friendly English manual for machine using and maintain.

(5) Spare parts will be offered for free.

(6) Professional design drawing such as 3D drawing can be designed and provided according to customer installation site.
