• Model NO.：S10
• Driven Type：DC
• Running Mode：Moving
• Feature：Aerial Work Platform
• Certification：GS, CE, RoHS, ISO 9001
• Installation：Tyre Crane
• Type of Work：Light Level
• Max.Working Height：12m
• Max.Platform Height：10m
• Loading Capacity：320kg
• Size of Platform：2.27×1.12 M
• Platform Extension Size：0.90×1.12 M
• Power：24V,3.3kw
• Battery：4×6V,225ah
• Max Climbing Ability：25%
• Total Weight：2620kgs
• Transport Package：Bulk
• Specification：SGS
• Trademark：KUDAT
• Origin：China
• Production Capacity：500PCS,Month

Basic Info.

Model NO. S10 Driven Type DC Running Mode Moving Feature Aerial Work Platform Certification GS, CE, RoHS, ISO 9001 Installation Tyre Crane Type of Work Light Level Max.Working Height 12m Max.Platform Height 10m Loading Capacity 320kg Size of Platform 2.27×1.12 M Platform Extension Size 0.90×1.12 M Power 24V/3.3kw Battery 4×6V/225ah Max Climbing Ability 25% Total Weight 2620kgs Transport Package Bulk Specification SGS Trademark KUDAT Origin China Production Capacity 500PCS/Month

Product Description

RELIABILITY EFFICIENCY E CONOMY SAFETY

We are dedicated to taking you higher by our reliable products, to realize more efficient and economic working at

Height. Our commitment doesn't end with the sale. We thrive on providing you more valuable safety equipment bystrict quality control and prompt services.

Rees has obtained the international IS09001 quality management certification. All machines have passed CE EN280certificate.

Reliability:

Key parts like power unit, electrical components are from global sourcing. Excellence of these key parts guaranteethe quality of REES products. We focus on improving quality and providing prompt services to make every REESequipment your reliable tool on worksite challenges.

Efficiency and Economy:

We listen to voices from customer, and solve all troubles which you may meet from the start of our design. Thismakes aerial work platform to be a efficient and economic tool for you. The lightweight maneuverability andcompact size make product a versatile option for a wide variety of rental, light-duty construction and mainte-nance applications in hotel,airport, housing property,industry workshop,warehouse..

Safety:

All our safety features are for your work at height. Emergency stop, Double hand operation button, and outrigger in-terlock will prevent injuries caused by incorrect operations. Cylinder blood proof valve and Emergency loweringbutton could prevent users from injury caused by machine malfunction.

CONFIGURATION:
1, Battery :Trojan from USA
2, Drive motor: Changba or Changqian from China
3, Charger : Keneng from China
4, Control system: DTC from USA
5, Group valve: Hydraforce from USA
6, Motor & braking : White from USA
7, Oil Pump: Bravini from ITALY
8, Tyre :Exmiletyre from China
9, Filter: Donaldson from USA


Model	S10
Max.working height	12m
Max.platform height	10m
Loading Capacity	320KG
Size of platform	2.27×1.12 M
Platform extension size	0.90×1.12 M
Overall stowed height(lift)	2.44M
Overall stowed height(lower)	1.92M
Overall stowed length	2.435M
Overall stowed width	1.15M
Power	24V/3.3KW
Driving speed-Eleveted	3.5KM/H
Driving speed -Lowered	0.8KM/H

Lift/Lower time	45/36sec
Battery	4×6V/225AH
Max climbing ability	25%
Maxmum slope	3°
Wheel size	φ381mm×127mm
Extend platform  safe working load	113KG
Total weight	2620KG
