CE/ISO China Factory Hot Sale High Quality No. 1 Approved Hydraulc Lift Machine Electirc Customized Sicssor Lift Tables
WUXI TONGYANG MACHINERY TECHNOLOGY CO., LTD.- Application:Workshop Crane, Shipboard Crane, Warehouse Crane, Building Crane
- Lift Mechanism:Electric Lift Table
- Carrying Capacity:1000kg
- Moves:Stationary
- Driven Type:Electric Hydraulic
- Running Mode:Stationary
Base Info
- Model NO.:YLF1001
- Feature:Explosion-Proof
- Certification:CE, ISO 9001
- Item:Ylf1001
- Platform Height Min:205
- Platform Height Max:990
- Platform Size:1300*820
- Base Size:1240*640
- Lift Time:20-25s
- Battery:380V,50Hz
- Net Weight:160kg
- Name:Factory Direct Sale Stationary Electric Lift Table
- Transport Package:Pallet with Stretch Film ,Cartons
- Specification:1300*820*205mm
- Trademark:Yinglift
- Origin:China
- HS Code:8428909090
- Production Capacity:5460sets,Month
Description
Basic Info.
Model NO. YLF1001 Feature Explosion-Proof Certification CE, ISO 9001 Item Ylf1001 Platform Height Min 205 Platform Height Max 990 Platform Size 1300*820 Base Size 1240*640 Lift Time 20-25s Battery 380V/50Hz Net Weight 160kg Name Factory Direct Sale Stationary Electric Lift Table Transport Package Pallet with Stretch Film /Cartons Specification 1300*820*205mm Trademark Yinglift Origin China HS Code 8428909090 Production Capacity 5460sets/MonthProduct Description
CE Approved Hydraulc Lift Machine Electirc Customized Sicssor Lift TablesModel | Capacity | Platform Height Min/Max | Platform Size | Base Size | Lift Time | Battery | Net Weight |
kg | mm | mm | mm | s | V/HZ | kg | |
YLF1001 | 1000 | 205/990 | 1300*820 | 1240*640 | 20~25 | 380/50 | 160 |
YLF1002 | 1000 | 205/990 | 1600*1000 | 1240*640 | 20~25 | 380/50 | 186 |
YLF1003 | 1000 | 240/1300 | 1700*850 | 1580*640 | 30~35 | 380/50 | 200 |
YLF1004 | 1000 | 240/1300 | 1700*1000 | 1580*640 | 30~35 | 380/50 | 210 |
YLF1007 | 1000 | 240/1300 | 1700*1500 | 1580*1320 | 30~40 | 380/50 | 365 |
YLF1008 | 1000 | 240/1300 | 2000*1700 | 1580*1320 | 30~40 | 380/50 | 430 |
YLF2001 | 2000 | 230/1000 | 1300*850 | 1220*785 | 20~25 | 380/50 | 235 |
YLF2002 | 2000 | 230/1000 | 1600*1000 | 1220*785 | 20~25 | 380/50 | 268 |
YLF2003 | 2000 | 250/1300 | 1700*850 | 1600*785 | 25~35 | 380/50 | 289 |
YLF2004 | 2000 | 250/1300 | 1700*1000 | 1600*785 | 25~35 | 380/50 | 300 |
YLF2005 | 2000 | 250/1300 | 2000*850 | 1600*785 | 25~35 | 380/50 | 300 |
YLF2006 | 2000 | 250/1300 | 2000*1000 | 1600*785 | 25~35 | 380/50 | 315 |
YLF2007 | 2000 | 250/1300 | 1700*1500 | 1600*1435 | 25~35 | 380/50 | 415 |
YLF2008 | 2000 | 250/1400 | 2000*1800 | 1600*1435 | 25~35 | 380/50 | 500 |
1.Load capacity up to 1000kg
2.With anti-pinch and overload protection function;
3.High quality pump station is with smooth lifting feature;
4.Heavy duty design 1000-4000kg;strong structure and steady performance;
5.External power pack equipped with a relief valve against overloading and a compensated flow valve for controlling lowering speed;
6.Upper platform fitted with safety perimeter to prevent descent on contact with obstructions.
FAQ:
1.Q.Are you factory?
A.Yes.Our factory mainly produce drum handling equipment,drum stacker,drum truck,aluminum hand trolley ,kinds lift table ,forklift attachment and shop crane with CE approved, pasted Third-party certification(SGS/ISO9001).
2.Q.Can I place mix order?
A.Yes.You can mix different models as your request.
3.Q.Can we order products?
A.Yes. Customers can option size,color,weighing,panel etc.Welcome ODM/OEM orders.
4.Q.Can we visit your factory?
A.Welcome anytime .Our factory address:No. 38, Yansheng Road, Yanqiao Industrial Park,Huishan District,Wuxi,Jiangsu,China (Mainland) .You can take the plane, high-speed rail, motor car, train, car.
5.Q.Are the products covered by a warranty?
A.Yes.All our machines carry a full 1 year major parts warranty.
Quality Control in our Wuxi Tongyang:
The quality control is strictly in accordance with ISO9001 quality management system. When the products are finished, the inspection is 100% executed strictly
1) Strict quality control system on the whole process of production
2) Imported key arts to ensure the high quality of our products
3) Advanced equipment and tools for examination and quality control
4) 100% strict examining products before shipment
5) All the quality complaints and improvement requirements are always studied seriously, if reasonable, put into practice immediately.
