• Model NO.：SPS-8
• Feature：Explosion-Proof
• Certification：CE
• Max Platform Height：7.99m
• Max Working Height：10.00m
• Platform Size：2.26*0.8m
• Load Capacity：230kg
• Extend Platform：900mm
• Max. Drive Speed(Stowed)：3.2km,H
• Color：Orange, Blue or According to Request
• Grade-Ability：25%
• Warranty：12 Months Apart From Man-Made Faults
• Maintenance-Free Battery：4*6,230V,Ah
• Transport Package：Nude Packing
• Specification：CE, SGS
• Trademark：MORN
• Origin：Shandong China
• HS Code：8428909090
• Production Capacity：200 Units Per Month

      Data/ModelSPS-6SPS-8SPS-10SPS-12SPS-14Lifting height(mm)61508000100001202014.26Max.working height(mm)78509700117001372015.96Min. Platform Height1060mm1190mm1320mm1530mm1740mmGround Clearance100/19mm100/19mm100/19mm200mm200mmLoad capacity(kg)380kg450kg320kg230kg320kgExtend platform length900mm900mm900mm900mm1100mmExtend platform capacity113kg113kg113kg113kg120kgPlatform Size(mm)2270*8102270*11202270*11202260*11302930*1650Overall size(mm)2480*810*10602480*1150*11902480*1150*13202485*1150*13102900*1750*1740Grade ability25%25%25%25%20%Min. Turning Radius219023302330mm
4500mmLift motor24V/3KW24V/3KW24V/3KW24V/3KW48/5 v/kwLifting up/lifting down speed22/34 sec30/33 sec30/38 sec33/39 sec33/39 secDrive speed(stowed)4.0km/h4.0km/h4.0km/h3.2km/h3.2km/hDrive speed(raised)0.8km/h0.8km/h0.8km/h0.8km/h0.8km/hMaintenance-free Battery4*6/210v/Ah4*6/210v/Ah4*6/210v/Ah4*6/230v/Ah8*6/215V/AhCharger24/25 v/A24/25 v/A24/25 v/A24/25 v/A48/50 v/AOverall Net Weight(kg)19502300273028503650

3. Power

1) Electricity or diesel: local power available at the working sites(110V,220V,380V,415V), diesel engines and generators.
2) It can be equipped with manual hydraulic device, so when there is no power at occasions or the power supply goes out, the lift can still work normally.


4. Safety

1) In special circumstance, the scissor lift can equip explosion-proof electric equipment.
2) The platform is equipped with antiskid plate to prevent slipping, it is enough safe when workers on the platform.
3) The lift has hydraulic overload protective organization to ensure that equipment will not lift when the load beyond its rated load capacity.
4) The scissor lift is equipped single control solenoid valves to prevent the platform dropping if power failure. You can open the manual dropped valve to lower the platform to the home position.


5. Main features of Morn scissor lifts

1) Quite and convenient
Battery power makes low noise and no emission when working

2) Scissor structure
The scissor structures are made by advanced CNC machine, which make every
lift parts extremely precise.

3) Flexible
The steering wheel can make a 90° turn in situ, can run in both high and low
speeds, and can used in small space.

4) Solid rubber wheels
The small solid rubber wheels moves slightly,  has no any damage to the floor

5) Larger working space
The platform can extend on one side, which can enlarge the working space

6) Folding guardrails
The guardrails of platform are folding and can reduce the height of the whole machine, which facilitates the transportation and pass of places such as openings.

7) Swing-out tray
The trays in both sides of the chassis can be swing out, which facilitate the maintenance, inspection and replacement

8) Battery brand-----Trojan with easy charging system for your convenient.

9) Maintenance schedules and other warnings are printed on the lift

10) Spare parts, some tools and operation manual, service manual will be sent with machine


6. Applications:


They are widely used for aerial installation and maintenance of the working sites without power supply and with smooth working grounds such as in factories, Star Hotels, restaurants, railway stations, airports theaters, exhibition halls, bus/railway stations, large factory, workshops, warehouse, granary, and other places. It's the best security partner together with maintenance of equipment, paint renovation, replacement lamps, electrical appliances, cleaning and maintenance and pipeline recondition etc.


7. Warranty

1) User-friendly English manual for machine using and maintenance.
2) One year warranty for whole machine without man-made fault;
3) We will send you parts for free if there are any non-human factors problem during warranty time
4) 24-hours technical support by email, telephone or other communication online.
5) We could reply you in 2 hours after received your any questions even on weekend and holiday, engineers are available to your country if necessary.
