• Model NO.：LRL0.25-1
• Feature：Explosion-Proof, Insulating
• Certification：CE
• Rated Loading Capacity：250kg
• Max. Lifting Height：1000mm
• Table Size：1200*1000mm
• Control System：Both on The Platform and Ground
• Remote Control：Optional
• Platform：Antiskid
• Emergency Stop：Manual Emergency Stop Valve
• Lock：Yes
• Installation：on The Ground, No Pit
• Warranty：12 Months Apart From Man Made Faults
• Transport Package：Plywood Case
• Specification：CE, SGS
• Trademark：MORN
• Origin：Shandong China
• HS Code：8428909090
• Production Capacity：200 Units Per Month

NameNo.Lift capacity (kg)MaterialsWheel-chair liftLRL0.25-1250Stainless steelPlatform size1200mm(L)* 1000mm(W)Dimension1200mm(L)*1450mm(W)* 1700mm(H)Max Platform Height1mMin Platform height60mmConfigurationOpen through or front and side entrancesSpeed60mm/sLoad capacity250KGControl voltage24V/DCPower Output1.1kwPower Input220V/50HZ/3Phase (or customized for local power supply)Drive SystemHydraulicControl ModeInching Switch and AutomaticOverloadProtection Over current relayMaterial of PlatformStainless steelGuard panel & drive cabinet (framework)304 stainless steelAutomatical rampYes or based on actual needOperation PanelPolished Stainless steel(up down and Emergency drop valve)Working ConditionBoth indoors and outdoorsWorking temperatureFrom -10°~60°CInstallation
 Non-pit installation, directly fixed to concrete floor (the concrete
floor below the platform shall not be lower than the ground)Control Device
 Calling box (installed on the wall nearby) and remote
controllerEmergency Stop
 The lifting and lowering process can be stopped immediately
by pressing the emergency button.


4. Safety device:

1. Safety Interlock: Lock the platform when the vertical platform lift encounters an emergency.
2. Safety Sensor: The operation must be stopped immediately the safety edge meets obstacles during operation.
3. Emergency lowering: The platform can be lowered by opening hydraulic valve manually or rolling screw rod.
4. Auto-flap: The small ramp will turn up while lifting.
5. Aluminum with tempered glass enclosure can be added per actual need.


5.  Guarantee & After-sales Services

1. User-friendly English manual for machine using and maintenance.
2. One year warranty for whole machine without man-made fault;
3. We will send you parts for free if there are any non-human factors problem during warranty time
4. 24-hours technical support by email, telephone or other communication online.
5. We could reply you in 2 hours after received your any questions even on weekend and holiday, engineers are available to your country if necessary.
