5t Offshore Air Winch

Yantai Petroleum Machinery Co., Ltd.
  • Type：Offshore Air Winch
  • Driven Type：Pneumatic Operated
  • Speed：8m,Min
  • Carrying Capacity：Middle-Level
  • Tonnage：5T
  • Reel Number：1

Base Info

  • Model NO.：JQHS50
  • Running Mode：Stationary
  • Feature：Explosion-Proof
  • Certification：CE, ISO 9001
  • Standards：ISO9001:2008; API; CCS; CE; ABS
  • Rated Pull Force：50kn
  • Rated Cable Speed：8 M,Min
  • Transport Package：Iron ,Plywooden Boxes, or as Customers′ Request
  • Specification：ISO9001: 2008; API; CCS; CE; ABS
  • Trademark：Dali
  • Origin：Yantai, Shandong
  • HS Code：84253990
  • Production Capacity：300sets Per Month

Description

Basic Info.

Model NO. JQHS50 Running Mode Stationary Feature Explosion-Proof Certification CE, ISO 9001 Standards ISO9001:2008; API; CCS; CE; ABS Rated Pull Force 50kn Rated Cable Speed 8 M/Min Transport Package Iron /Plywooden Boxes, or as Customers′ Request Specification ISO9001: 2008; API; CCS; CE; ABS Trademark Dali Origin Yantai, Shandong HS Code 84253990 Production Capacity 300sets Per Month

Product Description

5 Ton Offshore Air Winch with Disc Brake
Product Introduction
JQHS50 offshore air winch is a kind of manual operated single drum type air winch. It adopts
compressed air as its power to drive air motor, driving drum via two grades gears ( to reduce
transmitting speed and enlarge torque) so as to lift and drag heavy cargo. Considering
security, this winch is specially designed with hand brake and auto disc brake. This winch is widely
used for drilling, marines, minings, engineering sites, etc to pull heavy cargo.
Features
 1. Small in size, light in weight, high in mobility.
2. Flexible to perform clockwise and anti-clockwise rotation.
3. High practicability with anti-explosive function, especially stable and reliable in
inflammable, explosive, wet, damp, and other extremely working environments.
4. High starting torque enables start with load.
5. Anti-overload function.
6. Hand Brake and Auto Disc Brake.
7. ISO, API, CCS, CE, ABS etc.
Parameters
     Working Air Pressure (MPa)                        0.7-0.9
  Max. Pull Force at First Layer (kN)                          50
       Max. Rope Speed (m/min)                            8
          Air Consumption (L/s)                        247L/s
           Drum Size (mm)                    345*610*620
          Wire Rope Size                  φ16mm*400m
                Air Inlet (inch)                         1 1/4
                   Brake Type      Hand Brake+Auto Disc Brake
              Winch Size (mm)                      1600*1000*1100
                  Weight (kg)                           850
Yantai Petroleum Machinery Co.,Ltd is a factory to produce air winches for over 45 years and our winches can  be customized as to clients' requirements.
Welcome to visit our factory, any things, please contact us anytime.
