• Model NO.：deyuan
• Running Mode：Stationary
• Certification：CE, ISO 9001
• Standard：National Standards
• Driven Mode：Electric Operated
• Chain Size：12.5mm to 120mm
• Transport Package：1sets Per Wooden Case
• Specification：CCS, BV, GL.
• Trademark：Deyuan
• Origin：China
• Production Capacity：60sets Per Month

Basic Info.

Model NO. deyuan Running Mode Stationary Certification CE, ISO 9001 Standard National Standards Driven Mode Electric Operated Chain Size 12.5mm to 120mm Transport Package 1sets Per Wooden Case Specification CCS, BV, GL. Trademark Deyuan Origin China Production Capacity 60sets Per Month

Product Description

Boat Single Drum Mooring Winch for marine use


Boat Single Drum Mooring Winch for marine use
A mooring winch is one of the marine equipment used during mooring operations to hold a boat in place at a pier or similar fixture. Such winches may also be able to control anchors for mooring when port facilities are not available.

Mooring winch can operate effectively when dockship or docking port, and it has many functions. In the process of loading and unloading, it plays the role of drift, support and positioning, and adjusts the deviation of compensation vibration with constant tension

All our Hydraulic mooring winches are approved by CCS,ABS,DNV,BV,NK,RINA,BKI. Deyuan marine can offer you you all kinds of windlass and winch with hight quality and best price.

Anchor Windlass Features:
1) Drive: Electric / hydraulic
2) Configuration: Single in vertical / horizontal arrangement / double Gypsies in horizontal
3) Rope size: 12.5mm to 120mm
4) Chain speed: Complying with ISO requirements
5) Clutch: Manually operated dog clutch
6) Brake: Manually and hydraulic operated band brake
