• Model NO.：GTBZ14Z
• Feature：Telescopic Boom Lift
• Certification：CE
• Attribute (E. G.: Size)：Value (E. G.: 12 Inches)
• Structure：Telescopic Boom Lift
• Installation：Telescopic Boom Lift
• Type of Work：Telescopic Boom Lift
• Working Height：18m
• Platform Height：16m
•  Load Capacity：230kgs
• Travel Speed, Stowed：6.3km,H
• Total Weight：10t
• Power：42kw
• Transport Package：Nude in Container
• Specification：SGS CE
• Trademark：KUDAT
• Origin：China
• Production Capacity：800units,Months

Basic Info.

Model NO. GTBZ14Z Feature Telescopic Boom Lift Certification CE Attribute (E. G.: Size) Value (E. G.: 12 Inches) Structure Telescopic Boom Lift Installation Telescopic Boom Lift Type of Work Telescopic Boom Lift Working Height 18m Platform Height 16m  Load Capacity 230kgs Travel Speed, Stowed 6.3km/H Total Weight 10t Power 42kw Transport Package Nude in Container Specification SGS CE Trademark KUDAT Origin China Production Capacity 800units/Months

Product Description

Main Specification:

1.	Platform height maximum	16.2m
2.	Working height, maximum	18.2m
3.	Horizontal reach maximum	15m
4.	Maximum load capacity	230kgs
5.	Length(stowed)	7.895m
6.	Width	2.49m
7.	Height(stowed)	2.69m
8.	Wheel base	2.8m
9.	Ground Clearance-center	0.33mm
10.	Platform measurement	1.83*0.76m
11.	Turning radius, outside	5.2 m
12.	Turning radius, inside	3m
13.	Travel speed, stowed	6.3km/h
14.	Travel speed,raised or extended	1.1km/h
15.	Grade ability (boom stowed)	16.7°(30%)
16.	Tire size	36×14-20
17.	Swing speed	0~0.8rpm
18.	Turntable swing	360° continuously
19.	Platform levelling	Automatical levelling
20.	Platform rotation	±80°
21.	Fuel tank capacity	151L
22.	Total weight	10000kgs
23.	Voltage	12V
24.	Drive&steering type	4*2*2
25.	Engine	Cummins QSF2.8-C58/Yanmar 4TN94L-BXPHZ
26.	Rated power	42kw/2200 rpm/35.5kw/2200rpm
