Portable 1 Ton 2 Ton 3 Ton 5 Ton Hand Operated Small Crane Chain Hoist, Chain Block
Shanghai Yiying Crane Machinery Co., Ltd.- Application：Gantry Crane, Bridge Crane, Tower Crane, Single Grinder Crane, Lifting Platform, Small Crane
- Type：Chain Hoist
- Sling Type：Chain
- Lift Speed：2~8m,min
- Maximum Lifting Height：>20m
- Chain Falls：1
Base Info
- Model NO.：VC-B
- Certification：CE
- Condition：New
- Color：Orange
- Cover：Alloy
- Warranty：2 Years
- Request Lifting Capacity：Available
- Request Lifting Height：Available
- Zinc Hand Chain：Available
- Hook：Forged
- Delivery Time：10 Days
- Chain：G80
- Brand Name：Hugo
- Transport Package：Carton, Plywood, Pallet
- Specification：CE, ISO, TUV
- Trademark：HUGO
- Origin：Shanghai, China
- HS Code：8425190000
- Production Capacity：10000,Month
Description
The Paramters of VC_A 0.5T-50T Manual Hoist, Man Lift EquipmentModel VC-B 0.5 VC-B 1 VC-B 1.5 VC-B 2 VC-B 5 3 VC-B 5 VC-B 10 VC-B 20 VC-B 30 VC-B 50 Capacity(t) 0.5 1 1.5 2 3 5 10 20 30 50 Standard lift(m) 2.5 2.5 2.5 3 3 3 3 3 3 3 Running test load(t) 0.75 1.5 2.25 3 4.5 7.5 15 30 45 75 No.of falls of load chain 1 1 1 1 2 2 4 8 12 24 Load chain diameter(mm) 5 6.3 7.1 8 7.1 9 9 9 9 9 Dimension(mm) A 129 149.5 157.5 161.5 151.5 163 207 215 350 406 B 136 145 164.5 187 164.5 211 398 650 680 962 C 270 317 399 414 465 636 798 890 1380 2578 Net weight(kg) 8.4 12 16.2 20 24 41 79 193 220 1092 Packing(L*W*H)(cm) 22*14*15 25*19*16 33*24*16 33*24*19 34.5*24*16 40*30*19 48*42*18.5 78*68*20 85*67*30 110*100*130
