Power Battery Electric Pallet Jack
Niuli Machinery Manufacture Co., Ltd.- Type：Electric Jack
- Structure：Hydraulic Jack
- Capacity (Load)：1-10T
- Power Source：Electric
- Certification：CS
- Condition：New
Base Info
- Model NO.：CBD25
- Feature：Full-Electric
- Transport Package：Wooden Case
- Specification：NIULI
- Trademark：Niuli
- Origin：China
- HS Code：842700000
- Production Capacity：5000PCS
Description
Basic Info.
Model NO. CBD25 Feature Full-Electric Transport Package Wooden Case Specification NIULI Trademark Niuli Origin China HS Code 842700000 Production Capacity 5000PCSProduct Description
Electric Pallet Truck1) Capacity: CBD 2, 000kg, CBD2, 500kg
2) Max. Lifting height: 2, 00mm
3) Min. Fork height: 85mm
4) Fork length: 1, 220mm
5) Overall width: 820mm
6) Charging voltage: AC 220V
7) Battery charger: 24V/A, 30V/A, 40V/A
We can made special size Electric pallet truck for you according your special demands.
| Model | CBD20 | CBD25 |
| Capacity(kg) | 2000 | 2500 |
| Load Center(Qmm) | 600 | 600 |
| Front wheel size(mm) | φ80x70 | φ80x70 |
| Rear wheel size(mm) | φ130x55 | φ130x55 |
| Traction wheel(mm) | φ250x80 | φ250x80 |
| Max.lifting height(mm) | 200 | 200 |
| Fork clearance from ground(mm) | 85 | 85 |
| Fork Dimensions(Lmm) | 1200x160x60 | 1200x160x60 |
| Total length(L2L3mm) | 19902320 | 19902320 |
| Total width(Bmm) | 815 | 815 |
| Fork overall width(B1MM) | 550/680 | 550/680 |
| Turning radius (open pedal)(R1R2mm) | 18502150 | 18502150 |
| Self Weight(kg) | 600 | 660 |
| Battery volts/ampere | 2Vx12/210AH | 2Vx12/210AH |
| Battery charger | AC220V/50HZ/ DC24V/40A | AC220V/50HZ / DC24V/40A |
