New Brand Full Electric Stacker
Niuli Machinery Manufacture Co., Ltd.- After-sales Service：Online Service
- Warranty：1 Year
- Product Name：Full Electric Stacker
- Lifting Height：Customized
- Structure：Hydraulic Jack
- Power Source：Electric
Base Info
- Model NO.：CTQ
- Transport Package：Wooden Case
- Specification：NIULI
- Trademark：NIULI
- Origin：Heshan City, Guangdong Province, China.
- HS Code：8427900000
- Production Capacity：20000PCS
Description
Basic Info.
Model NO. CTQ Transport Package Wooden Case Specification NIULI Trademark NIULI Origin Heshan City, Guangdong Province, China. HS Code 8427900000 Production Capacity 20000PCSProduct Description
1. Capacity: 1000kg, 1300kg, 1500kg. 2000KG2. MAx Lifting Height: 1600mm, 2000mm, 2500mm, 3000mm, 3300mm. 3500-5500MM.
3. Min Forks Height: 85mm.
4. Fork Of Length: 1020mm.
5. Overall Width: 820mm.
6. Charhing Voltage: AC220V.
7. Battery Charger: 24/30/40 (V/A)
| Model | CTQ10/16,15/16,20/16 | CTQ10/20,15/20,20/20 |
| Capacity(kg) | 1000/1500/2000 | 1000/1500/2000 |
| Load center(Qmm) | 500 | 500 |
| Front wheel size(mm) | φ80x60 | φ80x60 |
| Rear wheel size(mm) | φ130x55 | φ130x55 |
| Traction wheel(mm) | φ250x80 | φ250x80 |
| Fork Dimensions(L3mm) | 1150x160x60 | 1150x160x60 |
| Max.lifting height(H2mm) | 1600 | 2000 |
| Extended height(H3mm) | 2080 | 2500 |
| Closed height H3(H1mm) | 2080 | 1580 |
| Fork clearance from ground(H5mm) | 80-90 | 80-90 |
| Total length(L1L2mm) | 2070/2360 | 2070/2360 |
| Total width(Bmm) | 815 | 815 |
| Max.fork width(B1mm) | 680 | 680 |
| Turning radius (open pedal)(R1mm) | 1950 | 1950 |
| Self Weight(without battery)(kg) | 710740750 | 730760770 |
| Battery charger | AC220V/50Hz DC24V/40A | AC220V/50Hz DC24V/40A |
