High Quality Manual Lever Hoist (LH-QA)
Hangzhou Nuohao Industry Co., Ltd.- Application：Double Beam Crane, Gantry Crane, Bridge Crane, Tower Crane, Single Grinder Crane, Lifting Platform, Small Crane
- Type：Lever Hoist
- Sling Type：Chain
- Lift Speed：<2m,min
- Maximum Lifting Height：>20m
- Chain Falls：2
Base Info
- Model NO.：LH-QA
- Certification：CE, ISO9001:2000, GS TUV
- Condition：New
- Color：Orange
- Capacity：0.25ton to 6ton
- Lifting Height：3m as Standard, Others Also Available
- Chain：G80 Load Chain and Galv. Hand Chain
- Transport Package：Carton Packing or Wooden Pallet Packing
- Specification：CE GS and TUV
- Trademark：LTN Or OEM
- Origin：Hangzhou China
- HS Code：8425190000
- Production Capacity：10000sets,Month
Description
| Model | LH-QA250 | LH-QA500 | LH-QA750 | LH-QA1500 | LH-QA2500 | LH-QA1600 | LH-QA3200 | LH-QA5000 | LH-QA6000 | |
| Capacity(Kg) | 250 | 500 | 750 | 1500 | 2500 | 1600 | 3200 | 5000 | 6000 | |
| Standard lift(M) | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | |
| Proof Load(KG) | 375 | 750 | 1125 | 2250 | 3750 | 2250 | 3750 | 7500 | 7500 | |
| Effort Required to Lift Max.Load(N) | 260 | 260 | 220 | 240 | 330 | 240 | 330 | 330 | 330 | |
| No.of falls of Load Chain | 4×12 | 4×12 | 5×15 | 7×21 | 9×27 | 7×21 | 9×27 | 9×27 | 9×27 | |
| Net Weight(Kg) | 2.2 | 3.2 | 4.7 | 7.6 | 14 | 8.4 | 14.8 | 22 | 22.8 | |
| Gross Weight(Kg) | 2.4 | 3.4 | 5 | 8 | 14.5 | 8.8 | 15.3 | 22.5 | 23.3 | |
| Diamensions(MM) | a | 86 | 95 | 121 | 139 | 173 | 139 | 173 | 173 | 173 |
| b | 155 | 178 | 204 | 235 | 286 | 235 | 286 | 340 | 340 | |
| c | 170 | 170 | 240 | 240 | 335 | 308 | 385 | 335 | 385 | |
| d | 30 | 35 | 30 | 42 | 52 | 42 | 52 | 60 | 60 | |
| e | 79 | 87 | 112 | 133 | 162 | 133 | 162 | 162 | 162 | |
| Hmin | 245 | 285 | 335 | 365 | 448 | 365 | 448 | 600 | 600 | |
| g | 97 | 117 | 124 | 159 | 178 | 157 | 184 | 178 | 184 | |
| h | 77 | 80 | 84 | 90 | 97 | 89 | 99 | 97 | 99 |
