• Model NO.：RSJ2412
• Feature：Explosion-Proof, Insulating
• Certification：CE, ISO 9001
• Delivery Time：15 Days
• Transport Package：Wooden Case
• Specification：CE Standard
• Trademark：SAMACH
• Origin：Shunde, Canton
• Production Capacity：200sets,Month

Basic Info.

Model NO. RSJ2412 Feature Explosion-Proof, Insulating Certification CE, ISO 9001 Delivery Time 15 Days Transport Package Wooden Case Specification CE Standard Trademark SAMACH Origin Shunde, Canton Production Capacity 200sets/Month

Product Description

Stationary Hydraulic Lifting Machine for Wood Working RSJ2412


1. standard (horizontal surface)             2. work with forklift       3. with drum

Stationary hydraulic platform is used for loading and unloading goods in the warehouse, workshop,
car and container. It can load and unload goods from the ground directly without cargo platform,
steel frames etc., the special designed movable transition slab can lap with car smoothly. It is
convenient to load and unload goods by forklift and manual hydraulic forklift smoothly. It plays the
role of the aerial work platform equipment perfectly. Torsional spring balance function of their
 transition slab make the operation easy, platform is flat with the ground after finished homework
 without occupying space on the ground and affecting the channel.

Parameters:

Model	RSJ2412 Standard	RSJ2412 With a forklifT	RSJ2412 With drum
Working table size	2400×1200mm	2400×1200mm	2400×1200mm
Max. lifting weight	3000kg	3000kg	3000kg
Min. working height	410mm	470mm	550mm
Max. working height	1100mm	1100mm	1100mm
Oil pump power	1.5kw	1.5kw	1.5kw
Radius of oil cylinder	90mm/2pcs	90mm/2pcs	90mm/2pcs
Overall Dimension(L*W*H)	2400×1200×410mm	2400×1200×470mm	2400×1200×550mm
Net weight	900kg	900kg	900kg

Details:
1. Power system: the three-phase asynchronous motor, water proof and explosion proof, high and low temperature resistance, environmental adaptation ability is stronger.

2.Lifting hinge plate
Support structure of hydraulic lift platform, high strength, flexible rotation is a basic requirement for lifting hinge
plate.
The machine adopts wide plate and special hinge shaft design to ensure the stable lifting goods considering the
 characteristics of the lifting platform.

3. Electrical part
It contains automatic circuit breaker, fuse, alternating current contactor,thermal relay, safety limited switch, foot
switch. Alternating current contactor and thermal relay protect the oil motor from overloading and loss of
 pressure. Automatic circuit breaker and fuse protect circuit from overloading and short circuit. Foot switch is
 used for controlling machine tool's lifting.

4. hydraulic pump station
It contains pumps, motors, cylinders, valves and tank.The lift of machine is done by a ¢90 mm cylinder. The
design of large diameter rod support good's weight effectively to ensure the safety of the lifting platform.

5.Workbench
It is welded by thick steel plate. Its structure fully considers workbench 's balance when lifting goods, ensuring
 hydraulic lift platform lift smoothly without loading. Standard size of platform is 2400 mm * 1200 mm (customized
 sizes based on customer requirements), there are three kinds of platform: 1. standard (horizontal surface);
2. work with forklift;  3. with drum.


Samach'S Services and dominants:

1: Professional team of techniques study and research, guarantee the Machine latest and improving efficiency.

2.Knowing China and world markets well, offer professional soluttions.

3.Fast market reaction,  guarantee our partners always in front edge.

4.Supeiror Guarantees,quality of our machine and sell-after service.

5.OEM/ODM are available.

6.Principle: One cooperation, forever partners.

Contact us and Enjoy our Happy Coopperation Together. Thank you for your time! ^_^
