• Model NO.：ECH-JD
• Certification：CE, ISO9001:2000
• Condition：New
• Color：Orange
• Warranty：1year
• Transport Package：Carton Packing or Wooden Pallet Packing
• Specification：CE, GS, TUV, ISO9001
• Trademark：LTN OR OEM
• Origin：Zhejiang, China (Mainland)
• HS Code：8425110000
• Production Capacity：300000 PCS,Month

Basic Info.

Model NO. ECH-JD Certification CE, ISO9001:2000 Condition New Color Orange Warranty 1year Transport Package Carton Packing or Wooden Pallet Packing Specification CE, GS, TUV, ISO9001 Trademark LTN OR OEM Origin Zhejiang, China (Mainland) HS Code 8425110000 Production Capacity 300000 PCS/Month

Product Description

With suspension hook. Push, geared or electric trolley.
Standard lift height 3 m, control cable 2.5m
Operating voltage 220-440V, 50/60Hz, 1-3 phase
Low voltage control 36V is standard.
High efficient energy-saving motor, asbestos free brake system.
High tensile aluminium alloy cover is light in construction, offers strong corrosion resistance.
Top and bottom hooks are fitted with safety latches as standard.
Drop forged steel suspension & load hooks are heat treated and fracture resistant. In case of dangerous overloading or abuse, the hook does not fracture but will slowly yield.
Solid chain bucket.
Super strong surface hardened chain
Limit switch devices fitted at both top & bottom ends, switch off power automatically to prevent load chain from running out.
The unique friction clutch overload protection, which protects the unit from overloading.
High quality electric components with safety protection.
Features
1) Brake: Adopting D. C. Normal close brake, without asbestos. Once the motor stop, the brake can hold the load safely and timely.
2) Electronic Limit Load Device: This hoist is equipped with electronic limit load device, which prevent chain being over tight.
3) Friction Clutch: Which can make the motor idle running to avoid damage under overload and over tight revolving.
4) Heat Protection Device: The motor is equipped with heat protection device, which preventing the motor to be damaged under overheat.
5) Hooks: Top and bottom hooks are made of high tensile alloy steel with special heat treatment. It prevents the hook from breaking and being deformed gradually under a sudden extra-load.
6) Load Chain: Load chain is carbonized with good wear property and long using life.
7) Chain Container: Chain container serves as a storage bag, keeping the load chain clear of dirt and dust, and without chuck while falling down freely.
8) Push Button Control: Push button control fits operator's hand operation. Impact and chemical atmosphere resistant.
9) Safety Latches: Top and bottom hooks are fitted with safety latches as standard
