• Model NO.：WL0.25-1.0
• Feature：Aluminum Ally
• Certification：ISO 9001
• Transport Package：Veneer Case
• Specification：WL0.25-2.0
• Trademark：MORN LIFT
• Origin：Shandong, China
• HS Code：842890
• Production Capacity：40set,Month

Basic Info.

Model NO. WL0.25-1.0 Feature Aluminum Ally Certification ISO 9001 Transport Package Veneer Case Specification WL0.25-2.0 Trademark MORN LIFT Origin Shandong, China HS Code 842890 Production Capacity 40set/Month

Product Description



1. platform sizes: 1330*900mm
2. Lifting height:1m
3. Loading capacity: 250kg
4. In or out direction
   180 degree/90 degree/one side open
5. Ramp: Automatic ramp/fixed ramp
6. Voltage: Ordinary:220v single-phase 50H / Factory:380v three-phase 50Hz
7. Control system
   Platform system/remote system/post system
   Key:  left-platform and post system(main control)
   right-remote system(auxiliary control)
   Middle-off

safety

1. safety sensor on the platform bottom
   Safety sensor connect limit switch,once touch the bottom,the lift will stop.
   In the process of descending the lift ,once the Children or pet enters the bottom of lift,the lift can stop and protect them.
2. Interlocking and electromagnetic lock
        Interlocking:the lift won't work if the door is open,lift only work when the door is completely closed
        Electromagnetic lock:the door won't be opened during the lift working
3. Mechanical platform lock
        It is a double safe design to people on platform
4. Emergency stop
        The first can be stopped immediately in case of any emergency when up or down
   And all three control system have an emergency stop.
5. Manual down
         the platform can be lowered by manual down button in case of power failure
6. Landing door
         Prevent the elderly and children from falling into well while waiting for the lift.
7. Non-slip platform
         Prevent the wheelchair sliding from platform during the lift ride.
8. Installation
   A,Easier for installation and transportation
   The body can be cut into two sections, there are iron plates in the tracks, just use screws to link the two sections instead of welding.
   Firstly it is easier for installation(indoor use),On the other hand, it can be easily put in a wooden box for transportation, can save some cost for you.
   B, Easier for fixation
   The connect beam that used to connect the lift and wall can be moved on
   the track, so it can be fixed on the wall at any height you want.
   C,Lifting hook
   The lift can be lifted up by this hook, it can also be taken down if you do not need it
    The machine and ground are respectively fixed and easy to install.
9. Material and packaging
   The first used T6030 aluminum ally,it has good mechanical intensity and corrosion resistance and weather resistance,which ensure the lift 15 years structural warranty at least.
   Hardness>2h,it is not easy to be scratched
   We make it white powder coating,it looks more beautiful,it can match with all kinds of buildings.

Optional :

enclosed wheelchair lift
home cabin wheelchair lift
