• Model NO.：BT26RT
• Feature：Explosion-Proof
• Certification：CE, ISO 9001
• Max. Working Height：26.32m
• Max.Platform Height：24.32m
• Max.Horizontal Reach：18.90m
• Ground Clearance：0.41m
• Wheelbase：2.80m
• Gradeability：45%
• Fuel：Diesel
• Transport Package：Nude Package
• Specification：10.82m*2.50m*2.89m
• Trademark：DINGLI
• Origin：Zhejiang, China
• HS Code：8427109000
• Production Capacity：1000units,Year

ModelBT26RTMax. Working Height26.32mMax.Platform Height24.32mMax.Horizontal Reach18.90mOverall Length(Stowed)10.82mOverall Length(Transport)10.77mOverall Width(Stowed)2.50mOverall Width(Transport)2.28mOverall Height(Stowed)2.89mOverall Height (Transport)2.57mPlatform Size(Length×Width)2.44m × 0.90mGround Clearance0.41mWheelbase2.80m ModelBT26RTS.W.L 454kgMax. Occupants3Turntable Tailswing1.61mTurning Radius (Inside/Outside)1.87m/3.22mTurret Rotary360° ContinuousPlatform Rotation180°Jib Movement135°Travel Speed (Stowed)≤6.0km/hTravel Speed (Raised)≤1.1km/hGradeability45%Maximum Working SlpoeX-5°/Y-5°Tyre385/45-28 ModelBT26RTEngine Deutz TD2.9 L455.4kWFuelDieselHydraulic Tank150LDiesel Tank135L ModelBT26RTWeight16090kg
