50ton Slipway Winch Pulling Vessel up and Down to Water
Pingyang Construction Hoisting Machinery Co.- Type：Electric Winch
- Driven Type：AC
- Speed：Slow
- Carrying Capacity：Special Weight Level
- Tonnage：30T
- Reel Number：1
Base Info
- Model NO.：JM
- Running Mode：Stationary
- Certification：ISO 9001
- Standard：National Standards
- Rope Speed：10m,Min
- Line Pull Capacity：50ton
- Rope Capacity：1000m
- Brake：Double Brake
- Transport Package：Naked
- Specification：with spooling device
- Trademark：CH
- Origin：China
- HS Code：8425319000
- Production Capacity：5 Units Per Month
Description
ModelJM12 JM16 JM20 JM25 JM30 Rated load (kg) 12000 16000 20000 25000 30000 Wire rope average speed (m/min) 9 6.6 7.7 8.5 8.5 Wire rope( mm): 32 36.5 39 42 48 Reduction box Type JZQ650 JZQ750 JZQ750 JZQ750 JZQ850 Transmission ratio 40.17 31.5 31.5 31.5 23.34 Drum (mm) Diameter(mm) 650 750 750 850 960 Length 1000 130 1830 1925 1960 Capacity(m) 500 600 600 700 650 Motor Type YZR250M2-8 YZR280S-8 YZR250M2-6 YZR280S-6 YZR280M-6 Power(kW) 37 45 45 55 75 Rotate speed(r/min) 725 717 965 969 969 Electric-hydraulic Brake Type YWZ-300 YWZ-400 YWZ-400 YWZ-400 YWZ-400 Dimension (cm) 250 x190 x 120 390 x300 x245 400x300x170 412 x300 x200 450 x300 x250 Weight(kg) 5500 7500 8500 9500 11000
