Hot-Selling China Economic Hydraulic Cylinder Lifting Table Option with Board

Ningbo Cholift Forklift Co., Ltd.
  • Lift Mechanism：Scissor Lift
  • Carrying Capacity：150-800kg
  • Moves：Manual
  • Driven Type：Hydraulic
  • Running Mode：Moving
  • Certification：CE, ISO 9001

Base Info

  • Model NO.：SPS
  • Overall Dimensions：910*500*52mm
  • Lift Table with Wheels Capacity：150kgs,350kgs,800kgs
  • Rated Loading Capacity：350kgs
  • Lift Drive / Actuation：Foot
  • Power：No
  • Lift Table with Wheels Lifting Height：950mm
  • Lift Table with Wheels Color：as Per Customer′s Request
  • Lift Table with Wheels Table Size：910*500*52mm
  • Lift Table with Wheels Max Lift Height：1300mm
  • Lift Table with Wheels Min Lift Height：350mm
  • Table Size：910*500*52mm
  • Weight：105kgs
  • Min. Lifting Height：350mm
  • Max. Lifting Height：1300mm
  • Lift Table with Wheels Weight：105kgs
  • Transport Package：Cartons and Pallets for Lift Table with Wheels
  • Trademark：CHOLIFT
  • Origin：Zhejiang, China
  • HS Code：84279000
  • Production Capacity：1000 Set,Sets Per Month Lift Table with Wheels

Description

Model (double sissor) SPS150SPS350SPS800Load capacity/rated loadkg150350800Max.lift heighth12 (mm)110013001500Min.height of tableh13 (mm)302350475Lifting heighth3 (mm)7989501025Table sizelxb5xs(mm)700*450*35910*500*521220*610*60Foot pedal cycles to max height ≤30≤60≤70Service weightkg64105172Carton sizemm860*485*300985*510*3501370*645*470



Hot-Selling China Economic Hydraulic Cylinder Lifting Table Option with BoardHot-Selling China Economic Hydraulic Cylinder Lifting Table Option with BoardHot-Selling China Economic Hydraulic Cylinder Lifting Table Option with BoardHot-Selling China Economic Hydraulic Cylinder Lifting Table Option with Board

 4. Certificate
