• Model NO.：1412
• Lift Drive / Actuation：Hydraulic
• After-Sales Service Provided：Online Support
• Warranty：2 Years
• Transport Package：Well
• Trademark：XCMG

ItemsParameters Dimensional parameters Overall dimensionsLength mm2850Width mm1250Height (with platform folded)mm2600Wheel basemm2240Wheel trackmm1123Traveling parameters Maximum traveling speed with platform not fully extendedkm/h≤3.2Maximum traveling speed with platform fully extendedkm/h≤0.8Minimum turning radius Outside m0Inside m≤2.65Minimum ground clearance mm100/20(with pit protector withdrawn/extended)Maximum gradeability%≥25Mass parameters Total weightkg3380Front axle kg1670Rear axle kg1710Batter Model  T1275Specification/ capacity V/Ah4×12/300Manufacturer  TrojanTire Specification  Traceless solid rubber tireDimensions mm×mm381×127Dimensions of work platform Length mm2636Width mm1120Height mm1255Position of mass center of complete platform Horizontal distance to front axlemm1127Height of center of massmm720Tilting warning angle Lateral °3Transverse °1.5Rated load of work platform kg230Maximum working height m≥15.7Maximum height of work platform m≥13.7Extension length of extended platform m0.9Rated load of extended platform kg115Minimum height of work platform m≤1.47Lifting speed of work platformm/s0.15~0.17Lowering speed of work platformm/s0.17~0.2
