• Model NO.：GTBZ38S
• Origin：Jiangsu, China, Cn; Jia

Item

Unit

Parameter

Overall length

mm

14060

Overall width (axle retracting/axle extending)

mm

2490/3800

Overall height

mm

3000

Wheel base

mm

3800

Max. working height

m

39.9

Max. platform height

 m

38.2

Max. working radius

m

23.3

Max. load capacity

kg

230 (no limit)/340 (with limit)

Boom elevation range

°

-7~+75

Turntable slewing angle

°

360°

Max. tail swing (axle retracting/axle extending)

mm

2085/1430

Platform dimension

mm

2400×900

Slewing angle of platform

°

180

Overall weight

kg

20600

Max. travel speed

km/h

5

Min. turning radius (axle retracting/axle extending)

m

8.2/10.8(turning for twice)

5.8/6.8(turning for four times)

Min. ground clearance

mm

260

Max. grade ability

%

40

Tire specification

-

445/50D710

Engine mode

-

Perkins 1104D-44T

Cummins B3.3-85HP

Engine rated power

kW/(r/min)

55.5/2400

63/2600
