Low Height Hydraulic Cylinder Jack (HHYG-B)
TAIZHOU RUIQI TOOLS CO., LTD.- Type：Portable Jack
- Structure：Hydraulic Jack
- Capacity (Load)：10~200 Ton
- Power Source：Hydraulic
- Max Height：100-150mm
- Certification：CE, ISO 9001:2000, ISO 9001:2008
Base Info
- Model NO.：HHYG-B
- Condition：New
- Tonnage：10~200 Ton
- Transport Package：Plywood Case
- Specification：CE, ISO9001: 2000
- Trademark：TLP
- Origin：China
- HS Code：84122100
- Production Capacity：3000PCS,Month
Description
| Model | Tonnage | Stroke |
oil capacity |
Matching pump |
Closed heigh |
G. W. | Volume |
| (T) | (mm) | (cc) | (mm) | (kg) | (mm) | ||
| HHYG-10B | 10 | 10 | 16 | HHB-700C | 48 | 1.5 | 150*65*50 |
| HHYG-20B | 20 | 10 | 28 | HHB-700C | 56 | 2.6 | 165*85*60 |
| HHYG-30B | 30 | 13 | 58 | HHB-700C | 60 | 3.9 | 185*100*65 |
| HHYG-50B | 50 | 16 | 113 | HHB-700C | 68 | 6.3 | 210*120*75 |
| HHYG-100B | 100 | 16 | 229 | HHB-700 | 86 | 14.5 | 250*170*100 |
| HHYG-150B | 150 | 16 | 342 | HHB-700 | 100 | 27 | 270*190*110 |
| HHYG-200B | 200 | 20 | 567 | HHB-700 | 110 | 42 | 330*220*120 |
