XCMG Gtbz24A High Quality Lift Platform Aerial Work Platform

XCMG E-Commerce Inc.
  • Other Country：Jiangsu, China, Cn;Jia
  • Type：Telescoping Lift
  • Trademark：XCMG
  • Origin：Jiangsu, China

Base Info

  • Model NO.：GTBZ24A

Description

Items

Unit

Parameters

a. Overall length

mm

11280

b. Overall width

mm

2490

c. Overall height

mm

3000

d. Wheel base

mm

3000

Maximum working height

m

26.08

Maximum platform height

 m

24.38

Maximum working amplitude

m

18.9

Maximum bearing capacity

kg

230

Luffing range of boom I

°

-1 to +70

Luffing range of boom II

°

-35 to +68

Slewing angle of slewing table

°

360°

Maximum tail wagging

mm

1330 (boom lifted)

Platform dimensions

mm

2400×900

Slewing angle of platform

°

180

Overall weight

kg

17800

Maximum traveling speed

km/h

5

Minimum turning radius

m

4.2m (four turns)/6.7m (two turns)

Minimum ground clearance

mm

260

Maximum gradeability

%

45

Tire specification

-

18-625

Engine model

-

QSF2.8 71BHP/KDI2504 TCR

Rated engine power

kW/(r/min)

53/(2200)/55.4/(2600)
