3 Ton Chain Block (CH-QA)
Hangzhou Nuohao Industry Co., Ltd.- Application：Double Beam Crane, Gantry Crane, Bridge Crane, Tower Crane, Single Grinder Crane, Lifting Platform, Small Crane
- Type：Chain Hoist
- Sling Type：Chain
- Lift Speed：<2m,min
- Maximum Lifting Height：12m
- Chain Falls：1
Base Info
- Model NO.：CH-QA
- Certification：CE, ISO9001:2000, GS TUV
- Condition：New
- Color：Orange
- Capacity：0.25ton to 10ton
- Lifting Height：3m as Standard, Others Also Available
- Chain：G80 Load Chain and Galv. Hand Chain
- Transport Package：Carton Packing or Wooden Pallet Packing
- Specification：CE GS and TUV
- Trademark：LTN Or OEM
- Origin：Hangzhou China
- HS Code：8425190000
- Production Capacity：10000sets,Month
Description
| Model | CH-QA250 | CH-QA500 | CH-QA1000 | CH-QA2000 | CH-QA3000 | CH-QA3000 | CH-QA10000 | |
| Capacity(Kg) | 250 | 500 | 1000 | 2000 | 3000 | 5000 | 10000 | |
| Standard lift(M) | 3 | 3 | 3 | 3 | 3 | 3 | 3 | |
| Proof Load(KG) | 375 | 750 | 1500 | 3000 | 4500 | 7500 | 15000 | |
| Effort Required to Lift Max.Load(N) | 220 | 240 | 305 | 360 | 370 | 390 | 430 | |
| No.of falls of Load Chain | 4×12 | 5×15 | 6×18 | 8×24 | 10×30 | 10×30 | 10×30 | |
| Net Weight(Kg) | 4.2 | 5.7 | 10.8 | 17.1 | 26.2 | 40 | 73.2 | |
| Diamensions(MM) | a | 95 | 114 | 152 | 190 | 240 | 240 | 240 |
| b | 94 | 114 | 144 | 184 | 214 | 214 | 214 | |
| c | 30 | 33 | 40 | 52 | 62 | 72 | 90 | |
| e | 99.4 | 110 | 139 | 150 | 158 | 158 | 858 | |
| Hmin | 259 | 309 | 373 | 460 | 553 | 630 | 158 |
